Shenzhen Sanray Technology Co., Ltd.

Home >Products Catalog > Active RFID Reader > 860-960MHz Android Passive Multiple Tag Long Range Handheld UHF RFID Reader

860-960MHz Android Passive Multiple Tag Long Range Handheld UHF RFID Reader

FOB Price:	165.00 - 680.00 USD/Piece
Supply Ability:	1,000 Piece(s) per Month
Shipping:	FOB shenzhen
Payment Terms:	D/A, T/T, Western Union, Other, paypal

In Stock

Inquiry Now

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Guangdong in China
Packaging Details:	standard package

Quick Details

Typical Applications:

Intelligent transportation management;

Asset identification, tracking and checking management;

Orientation, tracking and checking people in coal mine etc.;

Position monitor management for baby, prisoner, older psychotic etc..

Technology specifications
Operating frequency	2.4GHz~2.5GHz ISM
Antenna	Connect 1 antenna through SMA
RF power range	-30DBm~0.0dBm( adjusted by 32 grade )
Receiving sensitivity	-90.0dBm
Operating mode	FIxed frequency
Modulation	GFSK
Reading range	0~100m (Depend onDifferent gain omni-directional Antenna,) RSSI active reader can be adjusted less than 10m
Anti-collision	up to1000 tags read simultaneously
Communication speed	250kbps, 1Mbps, 2Mbps(adjustable)
Communication interface	RS-232, RS-485, Wiegand26/34/42/50, Ethernet
Input and output	2Input, 2 output
Power supply	AC input: 100~240V, 50/60Hz 1.2A DC output: 5V/1A
Product size	208mm125mm35mm(LWH)
Gross weight	0.79kg
Net weight	0.75kg
Working temperature	-20℃~+70℃
Storage temperature	-40℃~+85℃
Accessories	Standard matched antenna, Power adapter, Power cable, RS-232 cable, USB cable, Ethernet cable
Working status indication	Buzzer, LEDIndicator
