Alumina Ceramic Sleeve Lined Pipe Elbow for Mining

FOB Price: 5.00 - 20.00 USD/Piece
Supply Ability: 300 Piece(s) per Day
Payment Terms: L/C, T/T, Western Union, MoneyGram
In Stock

Related products from verified members

Export Markets: North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin: Jiangxi in China

Quick Details

  • Brand Name: chemshun ceramics
  • Material: Alumina Ceramic
  • Application: Industrial Ceramic
  • Type: Ceramic Rings
  • Color: white

Specifications

Chemshun Ceramics can offer kinds of engineered alumina ceramic pipe liner lined in steel pipe.Typical pipe liner includes alumina straight pipe liner, bend pipe tube and pipe tile liner. We have pipe tile liner like curved pipe tile liner, trapezoidal pipe tile, inter-lock pipe tile linings. They can suit all applications like pipe lengths and pipe bends,typical application is as cyclone liner. Pipe tile liner is much flexible and cost effective than ceramic pipe tube. Chemshun alumina pipe liner thickness includes 13mm, 25mm, 50mm.

Product characters:
   1)  Compared with integrated pipe liner, chemshun ceramic pipe tile liner is more cost effective in purchasing cost
  2)  Easy to be installed in equipment
  3)  Easy to repair when any piece ceramics damaged
  4)  Any size can be combined freely compared with integrated pipe.

Chemshun Size available (Length*width*thickness ):

150*100/95.63*50mm, 150*100/95.34*50mm 150*50/46*25 mm,
157*100*48/35 mm, 100/68*102/70*50 mm 125/62.2*102*50mm
80*23.9/22.1*20 mm 80*25.5/22.7*10mm 80*27.3/25.9*10 mm
80*27.4/25.73*8mm 80*28.5/27.3*10mm 25.4*25.4/24.4*12.7mm
97*50/48*15 mm 100*60/59.44*15mm
Note:  more sizes and customized size acceptable

Alumina ceramic sleeve lined pipe elbow for mining
 Alumina ceramic sleeve lined pipe elbow for mining
