Dps20-2.2kw Electrofusion Welding Machine

Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram, Safebuy

Inquiry Now

Quick Details

After-sales Service Provided: Overseas third-party support available
Usage: weld for hdpe /ppr pipe and fititngs
Weight: 10kg
Voltage: 220V
Brand Name: ZEMOWELD
Dimensions: 220mm
Frequency: 50/60HZ
Model Number: Dps20-2.2kw
Product Name: Electro Fusion Welding Machine HDPE
Input Voltage: 220V, 50/60Hz
Rated Power: 2.2kw
Rated Current: 50A
Rated Voltage: 55
Welding Specification: 20-200mm
WhatsApp: +86-13933031824

Specifications

Product Description

DPS20-2.2KW Electrofusion Welding MachineUsing true RMS control, is mainly used in connection of gas or water polyethylene (PE)
Pipes and fittings. It is the perfect corollary equipment for every PE pipe, pipe fitting manufactures and construction units.

the machine has higher performance than the international standard ISO12176-2 in welding voltage stability, welding time accuracy
and the temperature detection accuracy, etc.

Details Images

the main features are as follows:
? High-level MCU is used as control core, with abundant parameter setting, measuring and perfect protective function;
? High brightness liquid crystal display, support multi languages, touch button operation, man-machine interactive interface;
? Wide power supply and voltage input, suitable for on-the-spot electric network level;
? High precision control to electric energy and time, ensure welding quality;
? Swiftly output response time when power supply breaks, high stability;
? Support U disk reading welding record;
? Support U disk import formula parameter;
? Support USB portable printer, print welding record;
? with automatic identification matching pipe function;
? Good doubling protection function;
? with up to 6 phases programmable welding function, can adapt to different pipe welding requirements;
? Support a variety of welding parameters input: manual input, formula extraction, bar code scanning input;
? the control board adopts SMT welding technology to reduce the failure rate of the whole machine.

Product Paramenters

Electrofusion Welding Machine
Specification	Input Voltage(V)	Output Power (KW)	Output Current (A)	Output Voltage (v)	Welding Specification (mm)	Dimension (mm)(LXW
DPS20-2K2	AC220V±20%	2.5	50	55	Dn20-200	352X188X341
DPS20-3K5	AC220V±20%	3.5	55	75	Dn20-315	352X188X341
DPS20-6K	AC380V±20%	6	60	120	Dn20-400	480X273X440
DPS20-8K	AC380V±20%	8	60	150	Dn20-500	480X273X440
DPS20-12K	AC380V±20%	12	80	170	Dn20-800	480X273X440
DPS20-15K	AC380V±20%	15	80	210	Dn20-1200	480X273X440
