Metering Diesel Transfer Pump Mini Diesel Fuel Oil Dispenser

Supply Ability: 3,000 Unit(s) per Month
Shipping: FOB SHANGHAI
Payment Terms: T/T
Export Markets: North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin: Jiangsu in China
Packaging Details: 1SET/CTN

Quick Details

  • Pressure: Low Pressure
  • Standard or Nonstandard: Standard
  • Power: Electric
  • Structure: Gear Pump
  • Brand Name: OEM
  • Fuel: Diesel
  • Usage: Oil
  • Model Number: Mini Diesel Fuel Dispenser - 45L/Min 175W DC 12V/24V
  • Certificate: CE
  • Voltage: DC 12V/24V
  • Power: 175W
  • Speed: 4500R/Min
  • Flow: 50L/Min
  • Suction/Lift: 3m/7m
  • Suction Hose: 2m
  • Delivery Hose: 4m
  • Packing: 1SET/CTN
  • Applications: Diesel,Kerosene

Specifications

Metering Diesel Transfer Pump Mini Diesel Fuel Oil Dispenser

Metering Diesel Transfer Pump Mini Diesel Fuel Oil Dispenser

Diesel Kerosene Transfer Pump Kit 12V DC Portable Fuel Dispenser Self Priming Oil Bio 45LMin
Diesel Fuel Transfer Pump Kit - 175W DC 12V/24V
Certificate CE
Included Pump + Hoses + Fuel Nozzle
Voltage DC 12V/24V
Power 175W
Inlet/Outlet Dia 25mm
Impeller  Cast Iron
Flow 45L/Min
Suction/Lift 3m/7m
Suction Hose 2m
Delivery Hose 4m
Packing 1SET/BOX,2SET/CTN
Applications Diesel,Kerosene

Diesel Kerosene Transfer Pump Kit 12V DC Portable Fuel Dispenser Self Priming Oil Bio 45LMin
Metering Diesel Fuel Transfer Pump Kit Portable Dispenser
Certificate CE
Included Pump + Hoses + Metering Manual Nozzle
Voltage DC 12V/24V
Power 175W
Inlet/Outlet Dia 25mm
Impeller Shaft Cast Iron
Flow 45L/Min
Suction/Lift 3m/7m
Suction Hose 2m
Delivery Hose 4m
Packing 1SET/BOX,2SET/CTN
Applications Diesel,Kerosene

Diesel Kerosene Transfer Pump Kit 12V DC Portable Fuel Dispenser Self Priming Oil Bio 45LMin
Diesel Fuel Transfer Pump Kit Mini Dispenser - 175W DC 12V/24V
Certificate CE
Included Pump + Hoses + Auto Fuel Nozzle
Voltage DC 12V/24V
Power 175W
Inlet/Outlet Dia 25mm
Impeller  Cast Iron
Flow 45L/Min
Suction/Lift 3m/7m
Suction Hose 2m
Delivery Hose 4m
Packing 1SET/BOX,2SET/CTN
Applications Diesel,Kerosene

Diesel Kerosene Transfer Pump Kit 12V DC Portable Fuel Dispenser Self Priming Oil Bio 45LMin
Diesel Fuel Transfer Pump Kit Mini Dispenser - 175W DC 12V/24V
Certificate CE
Included Pump + Hoses + Metering Auto Fuel Nozzle
Voltage DC 12V/24V
Power 175W
Inlet/Outlet Dia 25mm
Impeller  Cast Iron
Flow 0-50L/Min
Suction/Lift 3m/7m
Suction Hose 2m
Delivery Hose 4m
Packing 1SET/BOX,2SET/CTN
Applications Diesel,Kerosene

Diesel Kerosene Transfer Pump Kit 12V DC Portable Fuel Dispenser Self Priming Oil Bio 45LMin
Diesel Fuel Transfer Pump Kit Mini Dispenser - 550W AC 220-240V
Art No AC Pump Kit
Certificate CE
Included Pump + Hoses + Manual Fuel Nozzle
Voltage AC 220-240V
Power 550W
Inlet/Outlet Dia 25mm/25mm
Motor Coil Material 100%Full copper
Flow 60L/Min
Suction/Lift 5m/10m
Suction Hose 2m
Delivery Hose 4m
Packing 1UNIT/BOX,2UNITS/CTN
Applications Diesel,Kerosene

Diesel Kerosene Transfer Pump Kit 12V DC Portable Fuel Dispenser Self Priming Oil Bio 45LMin
Diesel Fuel Transfer Pump Kit Mini Dispenser - 550W AC 220-240V
Art No AC Pump Kit
Certificate CE
Included Pump + Hoses + Auto Fuel Nozzle
Voltage AC 220-240V
Power 550W
Inlet/Outlet Dia 25mm/25mm
Motor Coil Material 100%Full copper
Flow 60L/Min
Suction/Lift 5m/10m
Suction Hose 2m
Delivery Hose 4m
Packing 1UNIT/BOX,2UNITS/CTN
Applications Diesel,Kerosene

Diesel Kerosene Transfer Pump Kit 12V DC Portable Fuel Dispenser Self Priming Oil Bio 45LMin
Diesel Fuel Transfer Pump Kit Mini Dispenser - 550W AC 220-240V
Art No AC Pump Kit
Certificate CE
Included Pump + Hoses + Metering Auto Fuel Nozzle
Voltage AC 220-240V
Power 550W
Inlet/Outlet Dia 25mm/25mm
Motor Coil Material 100%Full copper
Flow 60L/Min
Suction/Lift 5m/10m
Suction Hose 2m
Delivery Hose 4m
Packing 1UNIT/BOX,2UNITS/CTN
Applications Diesel,Kerosene

Diesel Kerosene Transfer Pump Kit 12V DC Portable Fuel Dispenser Self Priming Oil Bio 45LMin
Mini Diesel Fuel Dispenser - 45L/Min 175W DC 12V/24V
Certificate CE
Voltage DC 12V/24V
Power 175W
Speed 4500R/Min
Flow 50L/Min
Suction/Lift 3m/7m
Suction Hose 2m
Delivery Hose 4m
Packing 1SET/CTN
Applications Diesel,Kerosene

Diesel Kerosene Transfer Pump Kit 12V DC Portable Fuel Dispenser Self Priming Oil Bio 45LMin
Mini Diesel Fuel Dispenser - 45L/Min 175W DC 12V/24V
Certificate CE
Voltage DC 12V/24V
Power 175W
Speed 4500R/Min
Flow 50L/Min
Suction/Lift 3m/7m
Suction Hose 2m
Delivery Hose 4m
Packing 1SET/CTN
Applications Diesel,Kerosene

Diesel Kerosene Transfer Pump Kit 12V DC Portable Fuel Dispenser Self Priming Oil Bio 45LMin
Mini Diesel Fuel Dispenser - 60L/Min 550W AC 220-240V
Certificate CE
Voltage AC 220-240V
Power 550W
Frequency 50HZ
Inlet/Outlet Dia 25mm/25mm
Speed 2800R/Min
Flow 60L/Min
Suction/Lift 5m/10m
Suction Hose 2m
Delivery Hose 4m
Packing 1SET/CTN
Applications Diesel,Kerosene

Diesel Kerosene Transfer Pump Kit 12V DC Portable Fuel Dispenser Self Priming Oil Bio 45LMin
Mini Diesel Fuel Dispenser - 60L/Min 550W AC 220-240V
Certificate CE
Voltage AC 220-240V
Power 550W
Frequency 50HZ
Inlet/Outlet Dia 25mm/25mm
Speed 2800R/Min
Flow 60L/Min
Suction/Lift 5m/10m
Suction Hose 2m
Delivery Hose 4m
Packing 1SET/CTN
Applications Diesel,Kerosene

Diesel Kerosene Transfer Pump Kit 12V DC Portable Fuel Dispenser Self Priming Oil Bio 45LMin
220V AC Wall Mount Diesel Exhaust Fluid DEF Pump Kit
Certificate CE
Power 330W
Speed 3000R/Min
Flow 40L/Min
Pump Type Diaphragm
Housing Polyproplyene
Diaphragm TPU
Check Valve Viton
Check Valve Spring 316 Stainless Steel
Motor Shaft 316 Stainless Steel
Inlet/Outlet Dia 25mm
Max Working Pressure 40PSI ( 3 Bar )
Switch Setting Yes
Self Priming up to 5M vertically
Liquid Temperature No more than 60°C
Applications Adblue;Urea;Water




Submersible Diesel Fuel Transfer Pump - 51mm
Pump Body Material Stainless Steel; Aluminum; Plastic
Motor Case,Impeller Plastic - PP
Filter,Outlet Plastic - Nylon
Stator Material Magnetic Steel
Seal Material NBR
Switch 6A - 250AC
Voltage 12V/24V
Power 60W
Outlet Dia 19mm
Cable  3m
Overall Size 50.8 x 50.8 x 177mm
Flow 30L/Min
Lift 3m
Speed 8500 R/Min
Applications Diesel,Kerosene,Water

Submersible Diesel Fuel Transfer Pump - 38mm
Pump Body Material Stainless Steel; Aluminum; Plastic
Motor Case,Impeller Plastic - PP
Filter,Outlet Plastic - Nylon
Stator Material Magnetic Steel
Seal Material NBR
Switch 6A - 250AC
Voltage 12V/24V
Power 40W
Outlet Dia 19mm
Cable  3m
Overall Size 38 x 38 x 117mm
Flow 20L/Min
Lift 2m
Speed 8500 R/Min
Applications Diesel,Kerosene,Water

Diesel Kerosene Transfer Pump Kit 12V DC Portable Fuel Dispenser Self Priming Oil Bio 45LMin
Fuel Oil Diesel Transfer Pump - 45L/Min 175W DC 12V/24V
Voltage DC 12V/24V
Power 175W
Load Current 10 Amps
Inlet/Outlet Dia 25mm/25mm
Power Cable 2m
Flow 50L/Min
Suction/Lift 5m/10m
Net Weight 3.7KGS
Packing 1SET/BOX,6SET/CTN
Applications Diesel,Kerosene

Diesel Kerosene Transfer Pump Kit 12V DC Portable Fuel Dispenser Self Priming Oil Bio 45LMin
Diesel Fuel Oil Transfer Pump - 175W 45L/Min 12V/24V
Voltage DC 12V/24V
Power 175W
Load Current 10 Amps
Inlet/Outlet Dia 25mm/25mm
Power Cable 2m
Flow 50L/Min
Suction/Lift 3m/7m
Packing 1SET/BOX,6SET/CTN
Applications Diesel,Kerosene

Diesel Kerosene Transfer Pump Kit 12V DC Portable Fuel Dispenser Self Priming Oil Bio 45LMin
Diesel Fuel Transfer Pump - 70L/Min 550W DC 12V/24V
Voltage DC 12V/24V
Power 550W
Inlet/Outlet Dia 25mm/25mm
Power Cable 2m
Flow Rate 70L/Min
Suction 5m
Lift 10m
Packing 1SET/BOX,6SET/CTN
Applications Diesel,Kerosene

Diesel Kerosene Transfer Pump Kit 12V DC Portable Fuel Dispenser Self Priming Oil Bio 45LMin
Diesel Fuel Transfer Pump - 60L/Min 550W AC 220-240V
Voltage AC 220-240V
Power 550W
Frequency 50HZ
Load Current 2.5 Amps
Inlet/Outlet Dia 25mm/25mm
Power Cable 2m
Speed 2800R/Min
Flow 60L/Min
Suction/Lift 5m/10m
Packing 1UNIT/BOX,2UNITS/CTN
Applications Diesel,Kerosene

Diesel Kerosene Transfer Pump Kit 12V DC Portable Fuel Dispenser Self Priming Oil Bio 45LMin
Diesel Fuel Transfer Pump - 80L/Min 750W AC 220-240V
Voltage AC 220-240V
Power 750W
Frequency 50HZ
Inlet/Outlet Dia 25mm/25mm
Power Cable 2m
Flow 80L/Min
Suction 5m
Lift 10m
Packing 1UNITS/CTN
Applications Diesel,Kerosene

Diesel Kerosene Transfer Pump Kit 12V DC Portable Fuel Dispenser Self Priming Oil Bio 45LMin
12V Diesel Heating Motor Oil Extractor Pump
Maximum Current 5A
Maximum Power 60W
Sound Pressure Level 70dB(A)
Power Supply 12V- vehicle battery
Diesel/Heating Oil Flow Rate 250L/H
Motor oil (40-60 degrees) Flow Rate 1L/Min
Oil Extractor Pump Size 13 x 8 x 8.5cm ( L x W x H )
Input Hose 1.2m/6mm/4mm (Length/Outer Dia/Inner Dia)
Outlet Hose 1.5m/12mm/10mm (Length/Outer Dia/Inner Dia)
Packing 10PCS/CTN

Diesel Kerosene Transfer Pump Kit 12V DC Portable Fuel Dispenser Self Priming Oil Bio 45LMin
12V/24V 100W Engine Oil Transfer Pump
Theory Gear Pump
Voltage DC 12V/24V
Power 100W
No-Load Current 2.5A
Load Current 5A
Worke Cycle 30 Min
Flow 1-4L/Min
Inlet Tube 6mm x 800mm Copper Tube

8mmx1000mm PU Tube
Outlet Tube 10mmx1000mm PU Tube
Packing 12PCS/CTN


220V Engine Oil Transfer Gear Pump Motor 550W 20L/Min
Voltage AC 220-240V
Power 550W
Inlet/Outlet Dia 25mm/25mm
Cable Length 1.3M
Speed 1400R/Min
Flow 20L/Min
Suction/Lift 10m/20m
Packing 1UNIT/BOX,2UNITS/CTN
Net Weight 8.5KGS
Applications #32,46,68 engine oil or Hydraulic oil


Electric 12V/24V AdBlue Liquid Transfer Membrane Pump
Power 330W
Speed 3000R/Min
Flow 40L/Min
Pump Type Diaphragm
Housing Polyproplyene
Diaphragm TPU
Check Valve Viton
Check Valve Spring 316 Stainless Steel
Motor Shaft 316 Stainless Steel
Inlet/Outlet Dia 25mm
Maximum Working Pressure 40PSI ( 3 Bar )
Switch Setting Yes
Self Priming up to 5M vertically
Liquid Temperature No more than 60°C
Applications AdBlue;Urea;Water


Electric AC Adblue Transfer Diaphragm Pump 220V 40L/Min
Power 330W
Speed 2850R/Min
Flow 40L/Min
Pump Type Diaphragm
Housing Polyproplyene
Diaphragm TPU
Check Valve Viton
Check Valve Spring 316 Stainless Steel
Motor Shaft 316 Stainless Steel
Inlet/Outlet Dia 25mm
Maximum Working Pressure 40PSI ( 3 Bar )
Switch Setting Yes
Self Priming up to 5M vertically
Liquid Temperature No more than 60°C
Applications Adblue;Urea;Water


Electric Diesel Fuel Oil Transfer Drum Pump - 60L/Min
Voltage AC 110V 220V
Material Aluminum Alloy
Total Length 1.2m
Load Current 11.5Amps
Power 430W
Inlet Dia 44mm
Outlet Dia 25mm
Output Flowing 60L/Min
Suction 5m
Lift 10m
Cable 2m
Application Diesel,Kerosene,Water
Packing 1PC/BOX,10PCS/CTN


Electric Diesel Fuel Oil Transfer Drum Pump - 60L/Min
Voltage DC 12V 24V
Material Aluminum Alloy
Total Length 1.2m
Load Current 11.5Amps
Power 430W
Inlet Dia 44mm
Outlet Dia 25mm
Output Flowing 60L/Min
Suction 5m
Lift 10m
Cable 2m
Application Diesel,Kerosene,Water
Packing 1PC/BOX,10PCS/CTN


304 Stainless Steel Electric Chemical Barrel Pump
Voltage 220V
Power 0.88KW
Material 304 Stainless Steel
Suction Tube  304 Stainless Steel
Seal Material Viton
Vane Material  304 Stainless Steel
Spout Material 304 Stainless Steel
Inlet/Out Dia 50mm/25mm
Tube Length 1000mm
Output Flowing 110L/Min
Suction/Lift 5m/7.5mm
Speed 10000R/Min
Fits on 15 - 55 Gallon Drums
Applications Acid,alkali,diesel,machine oil,water, toluene,Uric acid
Packing 2PCS/CTN


316 Stainless Steel Electric Chemical Barrel Pump
Voltage 220V
Power 0.8KW
Material 316 Stainless Steel
Suction Tube  316 Stainless Steel
Seal Material Viton
Impeller Material  304 Stainless Steel
Spout Material 304 Stainless Steel
Inlet/Out Dia 42mm/25mm
Tube Length 1000mm
Output Flowing 150L/Min
Suction/Lift 5m/10mm
Motor Changable Speed
Max Viscosity 1200CPS
Fits on 15 - 55 Gallon Drums
Applications Acid,alkali,diesel,gasoline,machine oil,water, alcohol,toluene,Uric acid
Packing 2PCS/CTN


15L Electric Grease Pump
Capacity 15L
Material Steel
Overall Size 36 x 32 x 80cm
Voltage 220V/380V
Power 250W
Output flowing 0.25L/Min
Pressure ≤25-40mpa
High Pressure Hose 4M
Applicable NLG I0# - 3# Lubrications
Packing 1UNIT/CTN

25L Electric Grease Pump
Capacity 25L
Material Steel
Overall Size 39 x 38 x 86cm
Voltage 220V/380V
Power 1.1KW
Output flowing 0.35L/Min
Pressure ≤25-40mpa
High Pressure Hose 4M
Applicable NLG I# - 3# Lubrications
Packing 1UNIT/CTN


K24 Digital Flow Meter
Certificate CE
Material PPS
Connection Size BSPF1
Accuracy ±1%
Repeatability Error ±0.5%
Max Pressure 20Bar
Temperature Rang from -10℃ to +50℃
Working Voltage 2.3-3.3V
Standby Time  2 years
Flow Range 10L-100L/min
Single Count 0.00-999.99
Total Count 0.00-99999.99
Units L/GAL/PTS/QTS
Packing 50UNIT/CTN
N.W/G.W 15/16KGS
Carton Size 42 x 23 x 30cm
Applications Gasoline,Diesel,Kerosene,Water,Adblue


Aluminum Automatic Diesel Fuel Nozzle
Material Aluminum
Connection BSP/NPT Thread
Inlet Dia  BSPT/NPT 3/4'
Outlet Dia 13/16' & 15/16'
Flow Rate 0-60L/Min or 0-45L/Min
Color Red/Blue/Black
Nominal Pressure 0.18MPa
Self sealing time 0.1S (Max)
Net Weight 1.13KGS
Packing 1UNIT/BOX,10UNITS/CTN
N.W/G.W 13/14KGS
Carton Size 42 x 34 x 40cm
Applications Gasoline,Diesel,Kerosene

Service Process

Service Guarantee

  • Free Service Charge

    ECVV doesn't charge any service fee to Buyers for buying this product.

  • ECVV Supply

    ECVV is responsible for supply, and provides product quality inspection, fund supervision and supply chain services.

  • Product Quality Commitment

    ECVV China Sourcing Agent will assess the reputation and supply ability of the factory and conduct field trips to select the high-quality Chinese factories for buyers.

  • Deposit Service Commitments

    In order to improve the quality of service, ECVV will charge for a 100CNY deposit for the agent purchasing order, and the deposit will be part of subsequent purchasing costs.

    After paying a deposit, if the purchasing order is not completed because of unsatisfied ECVV services, ECVV will refund your deposit.

Engine Oil Transfer Gear Pump from this supplier

Food Grade Stainless Steel Gear Pumps Palm Olive Edible Oil Vegetable Soybean Oil Transfer Pump
FOB Price: 280.00-360.00 USD/Set
Min Order: 1 Set
Best Price Slurry Pump/Dredging Pump for River Sand Lifting
FOB Price: 1.00-1,245.00 USD/Set
Min Order: 1 Set
2cy Lubricating Oil Transfer Gear Pump
FOB Price: 200.00-600.00 USD/Set
Min Order: 1 Set
fuel oil transfer electric handle gear pump
FOB Price: 1.00-10.00 USD/Set
Min Order: 1 Set

More products from other suppliers

Oil Pump
Cast Iron Hand Pump
Min Order: 200 Pieces
2013 HOT heat pump,air source heat pump energy-saving by POWER WORLD
FOB Price: 500.00-1,200.00 USD/Piece
Min Order: 1 Piece
air pump
Min Order: 100 Pieces
Hand Operated Oval Bucket Oil Pump Gear Lube Dispenser - 20L
FOB Price: 18.30 USD/Piece
Min Order: 100 Pieces

Can't find a suitable Supplier or product? Entrust ECVV to purchase the well-chosen Chinese products with high cost performance.

Learn More>> Start Safebuy Order

Communicate with Supplier

Sourcing from ECVV
Join Facebook Group
