Changzhou Amc Flex Technology Co., Ltd.
China Manufacturer with main products: Waterproof LED Power Supply, Waterproof LED Driver, Constant Voltage LED Driver, Dimming LED Driver, LED Converter, LED Transformer, LED... |
75W 700mA IP67 Waterproof Street LED Driver
| FOB Price: | 10.00 - 15.00 USD/Piece |
|---|---|
| Supply Ability: | 20,000 Piece(s) per Month |
| Shipping: | shipping by sea |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union |
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Jiangsu in China |
| Packaging Details: | Packing: 0.55KG/PC, 350 x 310 x 260 mm, 24pcs /14.7Kg /0.02CBM/CTN |
Quick Details
- Brand Name: AMCFLEX
- Output Power: 75W
- Input Voltage: 176-305VAC
- warranty: 5years
- Output Voltage: 54-108VDC
- Model Number: APMS-75C-700
- PF: >0.95
- THD: <15%
- Output current options: 350W/500mA/700mA/1050mA/1400mA/1750mA/2100mA/2800mA/3500mA/4200mA
- warranty: 5 years
- application: led street lights, led floodlights, spotlights, tunnel lights, fishing light
Specifications
Product Features:
1. 176-305VAC wide input voltage range
2. Constant Current Drive Mode
3. Built in active PF function, PF>0,95
4. High working efficiency up to 90%
5. THD<15%, Flicker-Free Design
6. IP67 waterproof level with fine aluminum housing, suitable for outdoor applications
7. Class 2 Power unit
8. 4KV + 6KV Surge protection, more safety
9. 5 years warranty
1 |
Input | |||
NO |
Item |
Specs |
Unit |
Note |
1.1 |
Input voltage |
200277 |
Vac |
Typical 220Vac |
1.2 |
Input voltage range |
176305 |
Vac |
|
1.3 |
Input Frequency |
50/60 |
Hz |
|
1.4 |
Input Frequency Range |
4763 |
Hz |
|
1.5 |
Max Input current |
≤0.55 |
A |
Vin=200Vac,rated load |
1.6 |
Input inrush current |
≤20 |
A |
240Vac input,25℃ cold start |
1.7 |
PF |
≥0.95 |
Vin=200240Vac,rated load | |
1.8 |
THD | >15 | % | Rated input voltage, Rated load |
Model NO |
Input Voltage |
Output Voltage |
Output current |
Output Power |
Efficiency |
Dimension/mm |
| APMS-75C-350 | 200-277VAC | 107-214VDC | 350mA | 75W | 90% | 115x64x37 |
APMS-75C-700 |
200-277VAC |
54-108VDC |
700mA |
75W |
90% |
115x64x37 |
| APMS-75C-1050 | 200-277VAC | 35-71VDC | 1050mA | 75W | 90% | 115x65x37 |
APMS-75C-1400 |
200-277VAC |
27-55VDC |
1400mA |
75W |
90% |
115x64x37 |
APMS-75C-2100 |
200-277VAC |
18-36VDC |
2100mA |
75W |
90% |
115x64x37 |
APMS-75C-2800 |
200-277VAC |
13-26VDC |
2800mA |
75W |
90% |
115x64x37 |
APMS-75C-3500 |
200-277VAC |
11-22VDC |
3500mA |
75W |
90% |
115x64x37 |
