Julu Yuansheng Rubber Belt Co., Ltd.

China Manufacturer with main products: EP Rubber Belt, NN Rubber Belt, Rubber Belt, Conveyor Rubber Belt, Conveyor Belt, Heavy Rubber Belt, Chevron Rubber Belt, Sidewall Rubber...

Home >Products Catalog > Factory Price!! Industrial Flat EP/ Canvas Rubber Conveyor Belt

Factory Price!! Industrial Flat EP/ Canvas Rubber Conveyor Belt

FOB Price:	300.00 - 2000.00 USD/Roll
Shipping:	Tianjin port
Payment Terms:	L/C, T/T, Western Union

In Stock

Inquiry Now

Related products from verified members

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Hebei in China
Packaging Details:	Inner is packed on round rubber core with 30cm diameter and 12cmx12cm square hole. Outer is packed with one ply water-proof PP fabric

Quick Details

Brand Name: YUANSHENG
Color: BLACK
material: RUBBER
width: 400-1600MM
type: EP

Specifications

the EP rubber conveyor belt is made of multiple layers of polyester canvas in a certain way, and it is a wear-resistant rubber with high elasticity. It is used to transport small and medium-sized pieces, powders, granules and other materials without special corrosion. It is suitable for conveying materials in medium and long distance, high capacity and high speed circumstances.

1. Physical properties

Grade of covering rubber	Item	Tensile Strength		Elongation at break ≥ %	Abrasion ≤ (mm3)
Grade of covering rubber	Item	Mpa	Kgf/cm2	Elongation at break ≥ %	Abrasion ≤ (mm3)
Laceration resistant type	H	24	240	450	120
Abrasion resistant type	D	18	180	400	100
Ordinary type	L	15	150	350	200

2. Interlayer adhesion strength

Item	between the fabric layers	between cover rubber and Fabric
Item	between the fabric layers	Cover rubber thickness 0.8-1.5mm	Cover rubber thickness≥1.5mm
Average Value of all samples N/mm	≥4.5	3.2	3.5
Lowest Peak Value of all samples	≥3.9	2.4	2.9
Remark: Highest Peak value of all samples not more than 20N/mm

3. Types:

Product	Rubber conveyor belt
Type	Ordinary type, Heat resistant type, Flame retardant, Cold Resistant, Chemical resistant, Oil resistant etc.
Width	100mm-1600mm
Belt layer	2-8
Top Cover rubber	1.5-9mm
Bottom cover rubber	0-4.5mm
Belt material (Polyester)	EP100, EP150, EP200, EP250, EP300, EP400
Application	Mining, Port, Cement, Steel, Metallurgy, Electric Power, Coal, Machinery and Other industries.
Advantage	High tensile strength, Low Elongation, Good Flexibility, oil &heat & cold & Flame & chemical & impact & wear resistant
