EP10/15/18/24 FLAT Canvas Rubber Conveyor Belt

FOB Price:	300.00 - 2000.00 USD/Roll
Shipping:	Tianjin port
Payment Terms:	L/C, T/T, Western Union

In Stock

Inquiry Now

Related products from verified members

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Hebei in China
Packaging Details:	Inner is packed on round rubber core with 30cm diameter and 12cmx12cm square hole. Outer is packed with one ply water-proof PP fabric

Quick Details

Brand Name: YUANSHENG
Color: BLACK
material: RUBBER
width: 400-1600MM
type: EP
Model Number: ep

Specifications

Conveyor belt is the main part of the belt conveyor, which plays the role of carrying materials. It is widely used in metallurgy, building materials, electric power, docks, mining and other industries.

Compared with other modes of transportation, the conveyor belt as a transportation carrier has the advantages of safe operation, convenient use, easy maintenance, low freight, continuity, and shortening of transportation distance. Within a certain range, it has become a substitute for road and rail transportation. this kind of conveyor belt is suitable for conveying granular and powdery materials at room temperature without special corrosiveness.

Technical Standard: GB/T7984-2001

1. Physical properties

Grade of covering rubber	Tensile Strength Mpa ≥	Elongation at break ≥ %	Abrasion ≤ (mm3)
H	24	450	120
D	18	400	100
L	15	350	200

2. Thickness tensile properties

Longitudinal tensile strength of belt	≥160, 200, 250, 315, 400, 500, 600, 630. 800N/mm
Full thickness of the belt longitudinal elongation at break	≥10%
the full thickness of the belt longitudinal reference force elongation	≤4%
Straightness	≤25mm

Interlayer adhesion strength

Item

between the fabric layers

between cover rubber and Fabric

Cover rubber thickness

≤1.5mm

Cover rubber thickness≥1.5mm

Average Value of all samples N/mm

≥3.2

2.1

2.7
