Food Grade 304 Stainless Steel Welded Tube Mill Line Pipe Making Machine

FOB Price:	14800.00 - 296300.00 USD/Set
Supply Ability:	20 Set(s) per Year
Shipping:	shipment
Payment Terms:	L/C, T/T, Western Union

In Stock

Inquiry Now

Related products from verified members

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Guangdong in China
Packaging Details:	Waterproof Film and Pallets

Quick Details

After-sales Service Provided: Engineers available to service machinery overseas
Warranty: 1 year
Brand Name: Hangao Tech
Application: Energy Supply Pipe
Condition: New
Certification: ISO9001
Weight: pending
Dimension(L*W*H): customized
Power(W): pending
Voltage: 380V 50Hz
Model Number: SZG-30/40/50/60/80/100/120
Production Capacity: 1-7 M/Min
Pipe Material: Stainless Steel
Type: Pipe Production Line
Scope of Application: Medical Tube/Sanitary Pipe Making Machine
O.D. Range: 6-325 mm
Thickness: 0.38-10.0
Control Type: PLC
Production Speed: 1-7 M/Min

Specifications

Type	Material	Welding type	O.D. (mm)	Thickness (mm)	Motor Power (KW)	Size(LWH)(m)
SZG-30	SST	TIG	6-16	0.4-1.5	5.5	Customized
SZG-40	SST	TIG	16-50.8	0.5-2.5	7.5	Customized
SZG-50	SST	TIG	25.4-76	0.5-3.0	11	Customized
SZG-60	SST	TIG	50.8-114	1.0-4.0	15	Customized
SZG-80	SST	TIG	89-168	1.0-5.0	18.5	Customized
SZG-100	SST	TIG	114-219	2.0-8.0	30	Customized
SZG-120	SST	TIG	168-325	3.0-10.0	37	Customized

Usage
Hangao Tech food grade 304 stainless steel welded pipe mill line specializes in industrial usage, like HVAC pipe fittings, sanitary tubes, water pipes, valve pipe fittings, petrochemical pipes, chemical industry, medicine industry, wine-making industry, petroleum industry, food industry, automobile industry, paper making industry, air-condition making industry and so on. Products dealed with our tube mill could reach ASTM, DIN, ISO, GB and JIS standard.
