| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Guangdong in China |
| Packaging Details: | Waterproof Film and Pallets |
Quick Details
- After-sales Service Provided: Engineers available to service machinery overseas
- Warranty: 1 year
- Brand Name: Hangao Tech
- Application: Energy Supply Pipe
- Condition: New
- Certification: ISO9001
- Weight: pending
- Dimension(L*W*H): customized
- Power(W): pending
- Voltage: 380V 50Hz
- Model Number: SZG-30/40/50/60/80/100/120
- Production Capacity: 1-7 M/Min
- Pipe Material: Stainless Steel
- Type: Pipe Welding Machine
- Scope of Application: Medical Tube/Sanitary Pipe Making Machine
- O.D. Range: 6-325 mm
- Thickness: 0.38-10.0
- Control Type: PLC
- Production Speed: 1-7 M/Min
- Power Supply: 415V/3pH
Specifications
| Type | Material | Welding type | O.D. (mm) |
Thickness (mm) | Capacity (m/min) | Motor Power (KW) |
| SZG-30 | SST | TIG | 6-16 | 0.4-1.5 | Adjustable | 5.5 |
| SZG-40 | SST | TIG | 16-50.8 | 0.5-2.5 | Adjustable | |
| SZG-50 | SST | TIG | 25.4-76 | 0.5-3.0 | Adjustable | 11 |
| SZG-60 | SST | TIG | 50.8-114 | 1.0-4.0 | Adjustable | 15 |
| SZG-80 | SST | TIG | 89-168 | 1.0-5.0 | Adjustable | 18.5 |
| SZG-100 | SST | TIG | 114-219 | 2.0-8.0 | Adjustable | 30 |
| SZG-120 | SST | TIG | 168-325 | 3.0-10.0 | Adjustable | 37 |
Usage
Hangao Tech precision industrial stainless steel welded tube making machinery specializes in industrial usage, like HVAC pipe fittings, sanitary tubes, water pipes, valve pipe fittings, petrochemical pipes, chemical industry, medicine industry, wine-making industry, petroleum industry, food industry, automobile industry, paper making industry, air-condition making industry and so on. Products dealed with our tube mill could reach ASTM, DIN, ISO, GB and JIS standard.
