TY-5300-Digital Three-Clamp Phase Voltammeter

In Stock

Inquiry Now Start Safebuy Order

ECVV Safebuy Services

According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
Safebuy Service Guarantee

Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.

Export Markets:	South America, Eastern Europe, Southeast Asia, Africa, Mid East, Eastern Asia
Place of Origin:	Hubei in China

Quick Details

II Technical parameter

1.Fundamental and work condition

Influence quality	Fundamental condition	Work condition	Remark
Ambient temperature	25℃±1℃	-10℃40℃	----
Ambient humidity	40%60%	80%	----
Signal waveform	Sine wave	Sine wave	β0.01
Signal frequency	50Hz±1Hz	40Hz70Hz	----
Measure the voltage amplitude of the phase frequency Phase sequence power,power factor	100V±5V	1V600V	----
Measure the current amplitude of the phase frequency Phase sequence power,power factor	5A±0.5A	0.1A20A	----
External Electrical field, magnetic field	avoid
Position of Measured conductor	It is located at the approximate geometric center of the Clamp

2.Speification

Function	Measure Three-phase AC voltage, current, phase, frequency, phase sequence, active Power, reactive power, apparent power, power factor simultaneously, etc
Power	DC 7.4V,5000mAh lithium battery
Charger	DC 8.4V,2A special charge
Power consumption	Work around 40 hours continuously
Display mode	Color LCD Display 320dots240dots
Dimension
Current clamp size	L 130mmW 40mmH 20mm;Clamp :Φ7.5mm
Range	Voltage:AC 0600.0V (automatic shift )
	Current:AC 020.0A (automatic shift)
	Phase:0.0°360.0°
	Frequency:40Hz100Hz
	Active power:0.0W12kW
	Reactive:0.0VAR12kVAR
	Apparent power:0.0VA12kVA
	Power factor:-1+1
Resolution	Voltage:AC 0.001V
	Current:AC 0.001A
	Phase:0.1°
	Frequency:0.01Hz
	Active power:0.1W
	Reactive power:0.1VAR
	Apparent power:0.1VA
	Power factor:0.0001
Test speed	about 3s/time
