TY-563 Automatic 3 Phase Power Turn Ratio Tester

In Stock

Inquiry Now Start Safebuy Order

ECVV Safebuy Services

According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
Safebuy Service Guarantee

Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.

Export Markets:	South America, Southeast Asia, Africa, Mid East, Eastern Asia
Place of Origin:	Hubei in China
Packaging Details:	wooden box

Quick Details

II Performance

1.Three phase output simultaneously, apply to Various connections

2.Voltage ratio measurement,phase difference Measurement,excitation current measurement

3.Measuring time 5S, accuracy 0.1 class

4.Reverse wiring protection. Short-circuit protection ,overcurrent protection

5.Large screen display. Touched operation.

6.Power supply by 12V Lithium battery.Smart size ,weight 6.5kg

Technical parameter

Ratio measurement range::0.8-10000

Ratio measurement accuracy

Group measurement range:0-11

When Output voltage is high, 0.8-1000 0.1 class

When Output voltage is high, 1000-3000 0.2 class

When Output voltage is high, 3000-10000 0.5 class

When Output voltage is low, 0.8-100 0.2 class

When Output voltage is low, 100-500 0.5 class

Ratio relosution:0.0001

Angle resolution: 0.01

Angle accuracy: 0.1

Current measurement accuracy: 1%FS 2d

Primary measurement time: 5S

Power: 12VLithium battery, 5AH

Working temperature:-20℃ 40℃

N.W:6.5KG

Dimension:325mm*280mm *190mm
