HOT WHOLESALE TUNGSTEN CARBIDE CUTTING TOOLS / SOLID END MILLS for CUTTING METAL

Supply Ability:	10 Ton(s) per Month
Shipping:	TNT, EMS,DHL, Fedex,UPS , By Common Air ,By sea
Payment Terms:	L/C, T/T, Western Union

Inquiry Now

Related products from verified members

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Hunan in China
Packaging Details:	Carton , as customer requirement.

Quick Details

Type: Carbide End Mills
Brand Name: Ruiao
Application: Steel, stainless steel, die steel, mould steel, carbon steel, ect
Material: tungsten carbide, solid carbide , cemented carbide
Size: mertic@ inch size based tools
Model Number: standard
Coating: various coatings available, Altin,Tiain,Tisin, Tin, DLC,Nano, Diamoid
Helix angle: 10degree,15degree,25degree,35degree,45degree, 55degree
HRC: 45/55/58/60/55

Specifications

the following example is for you reference.

Main Advantages:

C=90%, Co=10%, TRS>4000N/mm2; Hardness>92HRA, Grain size: 0.5-0.6um; High qulaity of wearability and impact

1. with submicron grain size carbide
2. with TiAIN coating

3. with 2 flutes Flattened endmills, 2 flutes ball nose endmills, 3 flutes flattened endmills and 4 flutes flattened endmills, 4 flutes ball nose endmills, 6 flutes flattened endmills.

4. for machining hardened steel, alloy steel, cast iron, aluminium etc.
5. Special orders accepted
6. with stock available for standard sizes
7. Balzers coating

Technical details:

Specification Model
Diameter	Length of cutting edge	Total length	Diameter of the shank
1	3	50	4
1.5	4	50	4
2	6	50	4
2.5	7	50	4
3	8	50	4
3.5	10	50	4
4	10	50	4
4.5	13	50	6
5	13	50	6
5.5	15	50	6
6	15	50	6
7	20	60	8
8	20	60	8
9	25	75	10
10	25	75	10
11	30	75	12
12	30	75	12
14	35	80	14
16	45	100	16
18	50	100	18
20	50	100	20
