Coin Cell Crimping Machine for CR20XX Series

FOB Price:	1000.00 - 6000.00 USD/Piece
Supply Ability:	10 Piece(s) per Week
Payment Terms:	T/T

In Stock

Inquiry Now

Related products from verified members

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Oceania, Eastern Asia, Western Europe
Place of Origin:	Guangdong in China

Quick Details

After-sales Service Provided: No overseas service provided
Condition: New
Brand Name: TICO
Weight: 27
color: blue
Model Number: STC-SF120

Specifications

1.Brief Introduction:

the STC-SF120 compact hydraulic crimping machine is used for all types of coin cell cases crimping, such as CR2032, CR2450, etc. CR20XX series crimping die is included as standard, the other crimping die set is optional. Coin cell disassembly die and tablet pressing die can be optional.

2.Techincal parameters:

Model	STC-SF120
Standard crimping die	CR20XX crimping die, other crimping die is optional
Operation mode	Manual
Operation force of hand rocker	< 5.5kg
Dimension	L232 * W165 * H320mm
Weight	25kg

3.Performance features:

Stainless steel crimping die,anti-corrosion and durable
It's desinged with crimping height limitation to avoid damage
Embedded pressure gauge designed to observe and accurately control sealing pressure
No liquid leakage no vibration during battery sealing
Different die set can be optional, such as CR20XX /CR24XX crimping die, disassembly die,tablet pressing die etc. Easy to change different die set
Small volume, convenient operation, it can operate inside the glove box
