| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | China |
Quick Details
- Connection: Plug In
- Brand Name: ZWCX
- WARRANTY: 24 months
- Color: white / black
- Model Number: ZWCX251-P12020000
Specifications
Power supply 12v 1a
MAIN TECHNICAL DATA
Input Voltage/Frequency:100~240VAC 50/60Hz
Input No-Load Power:≤0.5W
Output Voltage Range:5.0~24.0VDC
Output Current Range:0.5~3.0ADC
Output Power Range:12~20W
Insulation:3KV/5mA
Ripple Wave:1%
Efficiency Level:IV
Output Protection Function: over Voltage Protection
over Current Protection
over Hot Protection
Short Circuit Protection
Working Temperature Range:0~25℃
Storage Temperature Range:-10~70℃
Overall Dimension:(L)76.0mm(W)32.0mm(H)51.5mm
Electromagnetism Compatibility Approval: FCC EMC
Security Approval: UL CUL GS CE SAA PSE EK CCC CB
Accord Standard: UL60950 EN60950 EN55022 J60950 EK60950 GB4943
STANDARD MODELS AND SPECIFICATION
Model |
Output Voltage (V) |
Output Current (A) |
Output Voltage Range (V) |
Remarks |
DCSP050300 |
5.0 |
3.0 |
4.7-5.3 |
Used for equipment |
DCSP090200 |
9.0 |
2.0 |
8.6-9.4 | |
DCSP120150 |
12.0 |
1.5 |
11.4-12.6 | |
DCSP180100 |
18.0 |
1.0 |
17.1-18.9 | |
DCSP240080 |
24.0 |
0.8 |
23.2-24.8 |
