2021 Arc Mma Yellow Arc Force Anti-Stick Sumerge Welding Machine
| FOB Price: | 25.00 - 35.00 USD/Piece |
|---|---|
| Supply Ability: | 100,000 Piece(s) per Month |
| Shipping: | by sea or train or air |
| Payment Terms: | T/T, Western Union, MoneyGram |
Related products from verified members
![manual welder machine / manual pvc windows machine -Ms Awen [008615063343341]](http://ic10.ecvv.com/upload/Product/20123/200x200/China_manual_welder_machine_manual_pvc_windows_machine_Ms_Awen_0086150633433412012381601377.jpg)
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Jiangsu in China |
| Packaging Details: | FOB ,CIF ( port of shipmet : shanghai ) |
Quick Details
- After-sales Service Provided: Engineers available to service machinery overseas
- Certification: ISO 9001-20000 Certificate
- Voltage: 220V
- Dimensions: 350*206*275
- Brand Name: paiwei
- Warranty: 1 year
- Usage: weld steel ,allium
- Motor Type: DC Motor
- Rated Duty Cycle: 80%
- Pilot Arc Current: 300A
- Arc Current: 300A
- Model Number: ARC-200/250/300
- Condition: New
- LOGO: can be accustomized
- color: can painting
Specifications
Type |
IGBT 1 PCB | IGBT 1 PCB | IGBT 1 PCB |
| Technology | DIP | DIP | DIP |
| Real Amp(A) | 120 | 140 | 160 |
| AC Input Voltage(V) | 220V | 220V | 220V |
| Rated Input Power Capacity(KVA) | 5 | 5.7 | 6.6 |
| Input Frequency(Hz) | 50/60 | 50/60 | 50/60 |
| Non-load Voltage(V) | 60 | 60 | 60 |
| Output current range(A) | 20-200 | 20-250 | 20-300 |
| Rated Duty Cycle(%) | 60% | 60% | 60% |
| Efficiency(%) | 85% | 85% | 85% |
| Class of Insulation | F | F | F |
| Protection class of case | IP21 | IP21 | IP21 |
| Electrode diameter(mm) | 1.6-3.2 | 1.6-3.2 | 1.6-4.0 |
| Quick joint Size | 35-50mm | 35-50mm | 35-50mm |
| Input power cable(m) | 1.8 | 1.8 | 1.8 |
| N.W./G.W.(kg) | 3.8/5.4 | 4/5.6 | 4.2/5.8 |
| Machine Size(LxWxH mm) | 310*137*225 | 310*137*225 | 310*137*225 |
| Package Dimension(LxWxH mm) | 350*206*275 | 350*206*275 | 350*206*275 |
| Accessories | 1.8m 16mm 200A holder 1.2m 16mm 300A clamp mask,brush | 1.8m 16mm 200A holder 1.2m 16mm 300A clamp mask,brush | 1.8m 16mm 200A holder 1.2m 16mm 300A clamp mask,brush |
