304 Stainless Steel Several Layers Sintered Metal Fiber Felt
| FOB Price: | 10.00 - 150.00 USD/Square Meter |
|---|---|
| Supply Ability: | 100,000 Square Meter(s) per Month |
| Shipping: | EXW or FOB Xiamen |
| Payment Terms: | T/T, Western Union, MoneyGram |
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Fujian in China |
| Packaging Details: | carton |
Quick Details
- Brand Name: QL
- Condition: New
- Medium Material: Stainless Steel, Nickel, Hastelloy, Fecralloy, Monel, Double-phase All
- Certification: ISO 9001 : 2015
- Weight: Customized
- Model Number: 1900*1200
- Size: Customized
Specifications
304 stainless steel several layers Sinteredmetal fiber felt for oil filter
Sintered metal fiber felt is manufactured from stainless steel fibers through lapping, laminating and high temperature diffusion-bonding (sintering). as a new type of porous material, the non-woven metal fiber has superior filtration function over wire cloth, for it has higher porosity, uniform distribution, greater dirt holding capacity, also can be welded, folded into different shapes. For its excellent filter performance, it is usually added into sintered mesh or sintered filter element as one layer. Multiple layers of metal fiber felt can also be sintered into filter media.
Features of sintered metal felt filter media
- High heat and corrosion resistance: Work temperature resistance can reach 1000 °C, and stainless steel or alloy for corrosive application, which non-metallic textile, ceramic or polymer product can not compete.
- High porosity: It performs with up to 85% high porosity, long on-stream lifetime, high flow rates.
- Low pressure drop: the high porosity allows a very low pressure drop, lower energy cost at the same time.
- Depth filtration: It enables you to achieve high efficient result through surface filtration and its high dirt capacity offers depth particles capture.
- Enhanced gel removal: Addition of metal fiber felt enhances gel removal property of sintered filter media and eliminates fiber breaks during spinning.
- Longer life: Stainless steel fiber felt is added into sintered filter media, onstream life can be increased by a factor of two to three times that of conventional wire mesh media.
Specification
- Material: 316-L stainless steel, 316 stainless steel, 304 stainless steel, nickel.
- Absolute filter rating: for liquids - 1m to 100m, for air and gases - below 0.1 m is possible.
- Size: as required
- Maximum size: 1200 mm 1900 mm. or required.
Property of sintered metal fiber felt (standard pressure and high pressure)
