DR8074A(HK01) IPQ8074A 4x4 2.4G 8x8 5G 802.11ax Wifi6 Router

FOB Price:	180.00 - 200.00 USD/Piece
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram, Safebuy

In Stock

Inquiry Now Start Safebuy Order

ECVV Safebuy Services

According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
Safebuy Service Guarantee

Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.

Packaging Details:	box

Quick Details

DR8074A(HK01) IPQ8074A 4x4 2.4G 8x8 5G 802.11ax wifi6 router

Features

Qualcomm Atheros A AR Quad Core CPU

on-board 5GHz radio, up to 4804Mbps physical data rate 32MB NOR Flash, 256MB NAND Flash

on-board 2.4GHz radio, up to 1147Mbps physical data rate

Support 11ax TX Beamforming

Support 11ac/ax MU-MIMO DL and UL

Support OFDMA DL and UL

Tri-band support with 5G SBS (4x4/5GHz + 4x4/5GHz) + 4x4/2.4GHz

Supports Dynamic Frequency Selection (DFS)

Absolute Maximum Rating

Parameter	Rating	Unit
Operating Temperature Range	-20 to +70	C
Storage Temperature Range	-40 to +90	C
Operating Humidity Range	5 to +95 (non-condensing)	%
Storage Humidity Range	0 to +90 (non-condensing)	%

Hardware Specifications

Symbol	Parameter
CPU	Qualcomm Atheros Quad Core ARM Cortex 64-bit A53 Processor 2.2GHz CPU
CPU Frequency	Derived from Qualcomm Atheros AP.HK01
System Memory	1GB (2x 512MB) DDR3L 32-bit interface
Frequency Range	2.412GHz to 2.472GHz, 5.150GHz to 5.825GHz
Modulation Techniques	OFDMA: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, 1024-QAM
NGFF Slot for 5G Module	M.2 (NGFF) " B Key" Socket with PCIe 3.0 interface
Optional Onboard Modules	Supports 1x BT module,1x ZigBee module,1x Touch pad connector,1x Audio header,1x LCD display header
Flash	NOR Flash: 32MB NAND Flash: 256MB EMMC: 8GB
Wireless	on-board 4x4 2.4GHz MU-MIMO 802.11b/g/n/ax, max TBDdBm per chain on-board 2x(4x4) or 8x8 5GHz MU-MIMO 802.11a/n/AC/ax, max TBDdBm per chain 12x U.FL connectors
Reset Buttons	2x Hardware reset button, 1x WPS reset button
DC Jack Input	1x DC Jack Connector: 12V, 5A
Interface	5x Gigabit Ethernet (1GbE) LAN/WAN RJ45 Port (Auto MDI-X) 1x 10Gigabit Ethernet (10GbE) LAN/WAN RJ45 Port (Auto MDI-X) 1x SFP+ Port 2x USB 3.0 Port 1x Serial Port 12 Pin Connector 1x JTAG 20 Pin Connector 1x micro SD Card Socket 1x M.2 Slot
LED	13x LED indicators, 2 additional LED on Ethernet port
Power Consumption	TBD
