Bucket-Tipping Mine Car Narrow-Gauge Railway Transportation Wagons
| Supply Ability: | 10 Carton(s) per Month |
|---|---|
| Shipping: | Guangzhou |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Hunan in China |
| Packaging Details: | Naked |
Quick Details
- After-sales Service Provided: No overseas service provided
- Condition: New
- Brand Name: Yutong
- Origin: China
- name: Mine car
- Model Number: KFU1.0-6
- Payment Terms: T/T, Paypal
- After-sales Service: Online Service
- Production Capacity: 10 Cartons/Year
- Color: Black
- Warranty: 1 Year
- Condition: New
Specifications
Bucket-tipping mine car narrow-gauge railway transportation waogon
Application, characteristics and working environment of bucket-tipping mine car
the bucket-tipping mine car is a narrow-gauge railway transportation vehicle for transporting coal, ore, ballast and other bulk materials in the mine. Generally, it must be tract by a locomotive or a winch.
According to different structures and unloading methods, they are divided into four categories: bucket-tipping mine car, fixed mine car, Single-side curved rail dumping mine car, and bottom-dumping mine car.
the main features of the bucket-tipping mine car:
the bucket-tipping mine car does not need any auxiliary facilities, can automatically flip left and right, is flexible and light.
the frame is a metal structure, which can withstand the traction force, Ultromotivity, collision force between mine cars, and rail impact force;
this type of mine car has the advantages of firm structure, beautiful appearance, reliable performance, flexible and stable operation, etc.
the frame of the mine car adopts a riveted welding structure, which reduces the influence of gravity on the mine car and increases the service life of the mine car.
the mine car is guaranteed to run smoothly whether in a bend or a straight.
this series of mining wagon are widely used for underground and surface coal transportation in coal mines,iron ore, phosphate mines, etc., It is
Commonly used transportation equipment such as coal mines.
K........Represents the mining vehicle
F........Represents bucket-tipping mine car
V/U........Represents the shape of the car box, V-shaped or U-shaped
0.75/1.0........Represents the volume of the car
-6.......Represents the gauge used by the car
Technical performance table of bucket-tipping mine car
| Volume | Nominal loading | Maximum loading |
Gauge | Dimensions | Wheel base | Wheel diameter | Haule height | Traction | Minimum plane operating radius | Body weight | Unloading angle | |||
| Length | Width |
High | ||||||||||||
| m3 | kg | kg | G mm | L mm | B mm | H mm | C mm | D mm | h mm | kN | m | kg | ° | |
| KFU0.75-6 | 0.75 | 1800 | 1800 | 600 | 1700 | 980 | 1250 | 600 | 300 | 320 | 60 | 9 | ≤740 | ≥40° |
| KFU1.0-6 | 1 | 2000 | 2500 | 600 | 1970 | 1070 | 1250 | 600 | 300 | 320 | 60 | 9 | ≤680 | ≥40° |
Locking mechanism test
Place the mine wagon car on a horizontal track, and open the left and right closing mechanism by manpower many times. the locking mechanism should be simple, reliable, safe, flexible and convenient in operation.
Braking mechanism test
Place the mine car on a horizontal track and run at a constant speed of 1.5-3.5m/s. When braking, check the reliability of the mechanism. the components of the mechanism should be firmly connected and braked reliably. When the force leaves the brake pedal the brake shoe should leave the wheel tread in time.
Wheel set test
the friction wheel or belt is driven by an electric motor, and the wheel is driven to run at a speed of not less than 500r/min for 10 minutes. the wheel rotates flexibly and the resistance torque is not more than 1370N.mm.
Locking mechanism test
When turning without load, the cart can be turned flexibly, and the unloading angle is ≥40°; after the locking mechanism is opened manually, the mine car can be easily and flexibly tipped to either side of its longitudinal centerline.
Buffer spring performance test
When metal springs are used, the compression performance test shall be carried out in accordance with the provisions of GB/T1239.4; when rubber springs are used, the compression performance test shall be carried out in accordance with the provisions of GB/T1684.
Attention during trial, maintenance and operation of bucket-tipping mine car
1.Before using the mine car, carefully check the appearance for any serious bumps and damage, and the wheels should rotate flexibly without jamming.
the case that the user abides by the rules for the use of mine car, within six months from the date of delivery, if it is damaged or cannot work normally due to poor manufacturing quality, the manufacturer shall repair or replace it free of charge.
Attention during trial, maintenance and operation of bucket-tipping mine car
1.Before using the mine car, carefully check the appearance for any serious bumps and damage, and the wheels should rotate flexibly without jamming.
the case that the user abides by the rules for the use of mine car, within six months from the date of delivery, if it is damaged or cannot work normally due to poor manufacturing quality, the manufacturer shall repair or replace it free of charge.
