Multiway Robotics (Shenzhen) Co., Ltd.
China Manufacturer with main products: Logistics Robotics Companies, Top Warehouse Robotics Companies |
Indoor Automated Tow Tractor2021
| FOB Price: | 100000.00 - 2000000.00 USD/Set |
|---|---|
| Payment Terms: | T/T |
Quick Details
- Type: Vacuum Cleaner
- Brand Name: /
- Certification: /
- Type: /
- Voltage (V): /
- Power (W): /
Specifications
Indoor tractor MW-ISP50, it is often used for the turnover and transportation of large quantities of goods in the workshop, such as the on-line of materials in the auto factory, auto parts, home appliances and other industries, and the off-line of finished products. The indoor traction unmanned forklift MW-ISP50 is often used for the turnover and transportation of large quantities of goods in the workshop, such as the on-line and off-line of materials in automobile factories, auto parts, home appliances and other industries. It is widely used in the transportation of raw materials in the factory, mobile assembly, goods on and off shelves, automatic transportation of finished products, automatic docking of production lines, intelligent picking and handling in the field of warehousing and logistics.
the Specification of MW-ISP50 Indoor Automated Tow Tractor
Standard Option
Standard Models |
MW-ISP50 Indoor Automated Tow Tractor | |
Navigation |
Laser+reflector navigation |
|
LiDAR SLAM navigation |
| |
Magnetic nails navigation |
| |
Hybrid navigation(LiDAR/Laser reflector+QR code/Magnetic nail) |
| |
Communication |
Wireless Wi-Fi |
|
Optical communication |
| |
5G |
| |
Specifications |
Payload(kg) |
5000 |
Tow traction payload(N) |
1000 | |
Dimensions LxWxH(mm) |
Customized | |
Turning Radius(mm) |
3000 | |
Ditch crossing capability(mm) |
≤30 | |
Obstacle crossing capability(mm) |
≤10 | |
Climbing capability(mm) |
≤3°(5%) | |
Weight(kg) |
880 | |
Motion capability |
Motion |
Reach, back, turning |
Auto hanging |
||
Speed(Unloaded/Max loaded)(m/s) |
1.5 | |
Accuracy(Bearing wheel center)(mm) |
±10 | |
Endangle accuracy(°) |
±1 | |
Stopping Accuracy(mm) |
±10 | |
Safety&protection |
Manual/Auto |
|
Offset protection, Abnormal positioning protection |
||
Components malfuction, communication fault protection |
||
Bottom front LiDAR anti-collision(1pcs) |
| |
3D obstacles avoidance(Top and front side 1pcs) |
| |
Bumper strip(Truck head) |
||
Emergency button(at least 2pcs) |
||
Sound(Speaker)alarm,Light alarm(3-color light) |
| |
Width light(Front 1pcs) |
||
HMI(7 inches) |
||
Monitoring camera |
||
3D visual offset |
||
Battery capability |
Automatic recharging |
|
Manual replacing and recharging (one truck one recharger) |
| |
Battery replacing(Standard) |
Side way replacing | |
Automatic charging bar |
Customized | |
Battery type(Standard) |
LiFePO4 | |
Voltage(V) |
48 | |
Standard capability(Ah) |
Customized | |
Operation time(h) |
Customized | |
Lifetime |
3000 times, 70% left | |
Recharging station(Standard) |
Customized | |
the Technical Details of MW-ISP50 Indoor Automated Tow Tractor
Environment adaption: Laser navigation, no need to set reflector, QR code or others that refit scenarios.
Intelligent running: Map building, path planning, auto recharging, self operating that meets various scenarios. Machine vision and comprehensive system enable Indoor Automated Tow Tractor, improving flexibility.
High accuracy, high efficiency: Primary positioning±5mm, secondary positioning±2mm.
Max speed 1.5m/s, max payload 5000kg, 724h full time running.
Intelligent, safe, easy to operate: Comprehensive self detection capability.
Safe sensors + dual control system protection, 360°Anti-collision, Light&Sound alarm protects.
Sustainable iteration, remote upgrading, friendly HMI.
the Applications of AGV Warehouse Tractor for Indoor Logistic
in the narrow lanes of warehouses, side-fork unmanned forklifts are often required for operations. the side-fork unmanned forklifts move along the horizontal rails. the forks are located on the sides of the forklifts. Turn first and then work.
Multiway Robotics is a, we provide,Agv warehouse,Omnidirectional mobile robotand etc. Want to know or more? Please contact us.
