AC Line Filter Safety Y1 Y2 Capacitors
| FOB Price: | 0.01 - 0.10 USD/Piece |
|---|---|
| Supply Ability: | 600,000 Piece(s) per Month |
| Payment Terms: | L/C, T/T, Other, Paypal |
-
ECVV Safebuy Services
According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
-
Safebuy Service Guarantee
Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|
Quick Details
- Rated Voltage: 400V, 300V, 500V
- Capacitance: 10pF to 10000pF
- Application: AC / Motor
- Type: Ceramic Capacitor
- Brand Name: JEC
- Operating Temperature: -40-125 degrees Celsius
- Package Type: Through Hole
Specifications
Specification Reference Standard |
IEC 60384-14; EN 60384-14; IEC UL60384; K 60384 |
Approved Monogram |
VDE / ENEC / IEC / UL / CSA / KC / CQC |
Subclass ; Rated Voltage(UR) |
X1 / Y1/Y2 ;400VAC / 300VAC/500VAC |
Capacitance Range |
10pF to 10000pF |
Voltage Proof |
4000VAC for 1min 2000VAC for 1min 1800VAC for 1min |
Capacitance Tolerance |
Y5P±10%(K) ; Y5U,Y5V±20%(M) measured at 25℃, 1Vrms, 1KHz |
Dissipation Factor (tgδ) |
Y5P,Y5U Tgδ≤2.5% ; Y5V Tgδ≤5% measured at 25℃, 1Vrms, 1KHz |
Insulation Resistance(IR) |
IR≥10000MΩ,1min,100VDC |
Operating Temperature |
-40℃ to +85℃ ; -40℃ to +125℃ |
Temperature Characteristic |
Y5P,Y5U,Y5V |
Flame Retardant Epoxy |
UL94-V0 |
Dongguan Zhixu Electronic Co., Ltd. (also JYH HSU(JEC))Factories are ISO-9000 and ISO-14000 certified. JEC X2, Y1, Y2 capacitors and varistors have passed these certifications:
CQC (China)
VDE (Germany)
CUL (America/Canada)
KC (South Korea)
ENEC (EU)
CB (International Electrotechnical Commission)
All of our capacitors are in line with the EU ROHS directives and REACH regulations.
FAQ
Q: What are the capacitance and rated voltage of ceramic capacitors?
A: Ceramic capacitors' capacitance can range from 1pf to 100nf. There are two common colors including earthy yellow and blue. Earthy yellow's rated voltage is generally 50V, 500V and 1KV while the rated voltage of the blue one is usually 500V, 1KV, 2KV, 3KV, 4KV and 6KV.
Q: how much is the shipping fees for the samples?
A: We need to know your address first because the shipping fees vary according to the address.
Q: What is the difference between blue and earthy yellow high voltage ceramic capacitors?
A: the blue ones are epoxy encapsulated, which gives them good moisture resistance and voltage resistance. The earthy yellow ones are wet encapsulation. that makes them damp easily and the voltage resistance is not so good compared to the blue ones.
