4.8x76m Cement Clinker Nickel Zinc Oxide Metallurgy Lime VerticalRotary Kiln

FOB Price:	1.00 - 99999.00 USD/Set
Supply Ability:	150 Set(s) per Year
Shipping:	shippemnt to Shanghai Port within 120 days
Payment Terms:	L/C, D/A, D/P, T/T

In Stock

Inquiry Now

Related products from verified members

Product Details

Export Markets:	Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Jiangsu in China
Packaging Details:	shippment by sea with container

Quick Details

After-sales Service Provided: Engineers available to service machinery overseas
Warranty: 2 years
Certification: available
Brand Name: Pengfei
Condition: New
Weight: according to different sizes
Dimension(L*W*H): according to different sizes
Power(W): according to different sizes
Voltage: according to different sizes
Model Number: according to different sizes
Production Capacity: according to different sizes

Specifications

48x76m Cement Clinker Nickel Zinc Oxide Metallurgy Lime VerticalRotary Kiln

1. Technical performance
Dry process precalcining kiln
Specification: Φ4.8*76m rotary kiln
Capacity: 5000t/d
Inclination: 4%
Rotary speed: Main driving 0.35-4 r/min;
Auxiliary driving 8.52 r/h
No. of support: 3
Sealing type: Kiln head, steel sheet sealing;
Kiln tail, cylinder compacting sealing
Cooling for kiln head: Air cooling
Type of thrust roller: Hydraulic thrust roller (with oil pump station for thrust roller)
Driving type: Single driving
Main driving motor: ZSN4-400-092
Power: 630 kw, Rotary speed: 1500r/min, Rated voltage: 440v
Main reducer: JH710C-SW305-40
Cooling coil cooling, center distance 1570mm, Nominal speed ration 40
Auxiliary motor: Y225M-4 IP44 45kw
Auxiliary reducer: JH220C-SV302-31.5

2. Major components
Shell part
Driving device
Supporting device ( Supporting device with thrust roller )
Oil pump station for thrust roller
Sealing device for kiln head and kiln tail
Cooling air pipe
Special tools for rotary kiln, etc
Total weight of equipment:
841000+13000 ( special tools for rotary kiln ) =854000kg

2.1 Shell part
2.1.1 Shell
Thickness of steel plate for shell: 28-85
Total weight of shell is 368000kg, including 20g is 366750kg, and the other is Q235.

2.1.2 Shim plate
the shim plate for the shell should adopt the more changeable structure type.

2.1.3 type
the type should adopt the rectangular and solid structure, its material is cast steel and it should normalizing treatsd
