Water Expansion Stop Ring Rubber Sealing Rings for Construction Purposes

Specifications

the product type water expansion waterstop is a new type of waterproof material which has both the performance of general rubber products and the performance of self-expansion in case of water. the water stopping and waterproofing effect is more reliable than the general rubber water stop.

Main features

the rubber will produce at least 1-5 times the expansion deformation after encountering water, and fill all the irregular surface of the joints, cavities and gaps, while producing a huge contact pressure, completely prevent leakage;

When the joints or construction joints are displaced, resulting in gaps beyond the elastic range of the material, the common type rubber water stop material loses its water stopping effect, while the product can also stop water by water absorption and expansion.

the use of water expansion rubber as a plug sealing water stopping material, not only the amount of savings, but also to remove the general elastic material due to excessive compression and elastic fatigue characteristics, so that the waterproof effect is more reliable, water resistance, chemical resistance and good aging resistance.

 It is mainly used in shield construction method now masonry joints waterproofing, building deformation joints, construction joints with water stops and metal components, concrete prefabricated components joints waterproofing.

Construction process

 for the pre-prepared paste method, in the first cast concrete need to be reserved on the waterstop placement slot (can be nailed in the formwork pre-prepared wooden strips).

after removing the concrete formwork, remove the surface to make the joint surface free of water, clean and debris.

Embed the waterstop into the reserved slot. If not reserved slot, for vertical joints can be added with binder full-length paste, or use cement nails with wooden strips to fix the waterstop; for horizontal joints can be directly pasted on the concrete surface.

the water-stopping strip should be pasted as soon as possible after pouring concrete. In the process of installation and paste, should prevent the water-stop strip from pollution and the role of water, so as not to affect the use of the effect.Installation method

Need to paste the construction joints of the fixed waterstop, the interface of the post-cast joints should be kept dry and smooth, and the interface should be cleared of scum, dust and things before construction. Waterstop installation site is determined, in the interface to be placed on the waterstop and the bottom of the waterstop meta-gas coated with a thin layer of adhesive, wait for the mucus to evaporate for a period of time and then paste, or use high-strength anchor nails to fix the waterstop in the installation site.

If the concrete interface is wet or uneven, the adhesive paste is not fixed, depending on the specific situation with high-strength anchor nails to further strengthen the fixed. In short, the waterstop must be in close contact with the concrete interface fixed solid, to prevent the waterstop from the interface and promote the role of anti-seepage.
