Hangzhou Link Digital Tech Co., Ltd.
China Manufacturer with main products: PTZ Camera, Thermal Camera, Analog Camera, Network Camera, IP Camera, Marine Camera, PTZ Thermal Cameea |
Network Thermal PTZ Camera 1080P30 Analog Video
| FOB Price: | 3000.00 - 6000.00 USD/Piece |
|---|
Related products from verified members
Quick Details
- Special Features: Waterproof / Weatherproof
- Technology: Pan / Tilt / Zoom
- Sensor: CMOS
- Type: Analog Camera
- Brand Name: Link
- Model Number: Link-750
Specifications
| Model | Link-750-NH319 | Link-750-NH619 | |
| IR Camera | |||
| Image Sensor | Uncooled Microbolometer FPA(Amorphous silicon) | ||
| WorkingBand | 8μm~14μm | ||
| Spectral Resolutions | 384x288 | 640x480 | |
| Sensor Size | 17μm | ||
| NETD | ≤50mk@300K | ||
| E-Zoom | 1-4X | ||
| Lens | 19mm | ||
| FOV |
19.5° x 14.7° | 32° x 24.2° | |
| Color Palettes | 14 | ||
| Detecting Range | Vehicle:2570m Man:550m | ||
| Measurement (optional) | |||
| Temperature measurement | -20℃ ~ +550℃ | ||
| Accuracy | ± 2℃ or ± 2% of reading | ||
| Measurement Modes |
Global,spot, area, isotherm, line profile,alarm for temperature above or below | ||
| VS Camera | |||
| Image Sensor | 1/2.8" Exmor CMOS, 2.13MP | ||
| Effective Pixel | 16: 9, 2.13 megapixel | ||
| Video Format(NET) | 1080P/30, 1080P/25, 720P/60, 720P/50, 720P/30, 720P/25 | ||
| Video Format(SD) | PAL/NTSC | ||
| Optical Zoom | 30X | ||
| Digital Zoom | 12X | ||
| Horizontal Field of View | 63.7° ~ 2.3° | ||
| Lens | 4.3 mm to 129.0 mm | ||
| Digital Noise Reduction |
1~5 Steps | ||
| Day/Night ICR | Auto/Manual | ||
| WDR |
on/off | ||
| Focus | Auto | ||
| Exposure | Auto | ||
| Image Stabilization |
on/off | ||
| Network | |||
| Image Resolution | Max:1920*1080@30fps | ||
| Image Compression | H.264, H.265 | ||
| Image Code Stream | Dual streams output | ||
| Protocols | HTTP, RTSP, TCP, UDP, ONVIF | ||
| Ethernet Interface | 10 / 100M | ||
| Interface | |||
| Video Output | 1 Channel Thermal Imaging Video or 1 Channel Visual Video; BNC | ||
| Comm Interface | RS485 | ||
| PTZ | |||
| Pan Range | 360°Continuous | ||
| Pan Speed | 0.1° ~ 80°/s | ||
| Tilt Range | -20° ~ 90° | ||
| Tilt Speed | 0.1° ~ 60°/s | ||
| General | |||
| Communications | Pelco-D / Pelco-P Protocol | ||
| Baud Rate | 2400/4800/9600/19200 self-Adaptive | ||
| Address | 0-255(soft address) | ||
| Menu Language | English | ||
| Environmental | IP66 | ||
| Dimensions | Φ147mm x 205mm Height | ||
| Power Supply | 10V-24V 35W Max(Motor Drive & Illumination On) | ||
| Operating Temperature | -25℃ ~ +55℃ | ||
