Professional Factory S1100 Ventilation Machine Medical Equipment Ventilators for Hospital ICU Use

FOB Price:	5500.00 - 9500.00 USD/Set
Shipping:	express, sea, air, ground
Payment Terms:	L/C, T/T, Western Union, MoneyGram

In Stock

Inquiry Now

Related products from verified members

Product Details

Export Markets:	Southeast Asia, Africa, Eastern Asia
Place of Origin:	Jiangsu in China
Packaging Details:	Main components: L 560 * W 560 * H 605 mm, G.W. : 35 KG, N.W. : 17 KG Air compressor: L 670* W 700 * H 1160 mm, G.W. : 79 KG, N.W. : 46.2 KG

Quick Details

Brand Name: Nanjing Superstar
Properties: Ventilation System
Size: L 560 * W 560 * H 605 mm, G.W. : 35 KG, N.W. : 17 KG
Thickness: 560
Power Supply: Electric
Model Number: S1100
Material: Metal, Plastic, Environmental material
Shelf Life: 2 years
Instrument classification: Class III
After-sale Service: Online technical support
Safety standard: GB15979-2002
Packing: Wooden Case
Certificate: CE ISO
Usage: Breathing support

Specifications

Product Description
Product Application

the ventilator is suitable for various kinds of medical institutions for cardiopulmonary resuscitation respiratory support. Acute respiratory failure caused by various reasons or incomplete oxygenation dysfunction. Indra-operation, post-operation respiratory support, other respiratory treatment.
Main Features15" TFT LCD touch screen displays the ventilation parameters, alarm information and waveforms.

Air compressor runs stably with low noise, creates quiet environment for doctors and patients.

Integration breathing circuit design.

Multiple working modes such as volume control and pressure limit.

Multiple parameters monitoring interface to show clear parameter to the operator, allow operator know the patient conditions in all aspects.

Real time pressure-time, flow-time loop graphics, pressure volume loop graphics and high precision ETCO2, O2 concentration detection      function included.

Electrical PEEP control

Breathing valve is disassembly and can be disinfected.

SPECIFICATIONS for S1100 ICU VENTILATOR

Ventilation modes:	IPPV, A/C, PCV, SIMV, SPONT/CPAP, PSV
Ventilator parameter	Tidal volume(Vt)	0 2000mL
	Frequency (Freq)	1bpm 100 bpm
	Oxygen concentration	21%-100%
	I/E	4:11:8
	PEEP	0cmH2O 40 cmH2O
	Pressure Limit	20 cmH2O 100 cmH2O
Monitored Parameters	Frequency (Freq)	0 /min 100 /min
	Tidal volume(Vt)	0 mL 2500 mL
	MV	0 L/min 99 L/min
	Airway pressure	1mL/cmH2O 1000mL/cmH2O
	Dynamic lung compliance testing	1mL/cmH2O 1000mL/cmH2O
	ETCO2 Concentration	0mmHg 152mmHg (0%-20%)
	Oxygen concentration	15 % 100 %
	ETCO2 Concentration	0mmHg 152mmHg (0%-20%)
	Oxygen concentration	15 % 100 %
Oscillographs display	P-T(pressure time)
	F-T(flow time)
	P-V loop (pressure volume loop)
	V-T(volume time )
	ETCO2-T (End-tidal CO2 - time)
Alarms and protection	the AC power failure alarm	Power failure or no connection
	Internal battery backup low voltage alarm	≤11.3±0.3V
	No tidal volume	No tidal volume within 6s
	High Minute Volume alarm	5L/min-99L/min
	Low Minute Volume alarm	1L/min-30L/min
	High Airway pressure alarm	20cmH2O-100cmH2O
	Low Airway pressure alarm	0cmH2O-20cmH2O
	High oxygen concentration alarm	19%-100%
	Low oxygen concentration alarm	18%-99%
	Continuous pressure alarm	(PEEP+1.5cmH2O) over 16s
	Suffocation warning	5-60s
	Fan error	Show on screen
	Oxygen deficit	Show on screen
	the maximum limited pressure	12.5 kPa
Working conditions	Gas source	O2, AIR
	Pressure	280kPa-600kPa
	Voltage	220V±22V
	Power frequency	50Hz ± 1Hz
	Input power	900VA (with air compressor)
		250VA (without air compressor)
Parking size	Main components: L 560 * W 560 * H 605 mm, G.W.: 35 KG, N.W.: 17 KG
	Air compressor: L 670* W 700 * H 1160 mm, G.W.: 79 KG, N.W.: 46.2 KG

Packing & Delivery
Professional Factory S1100 Ventilation Machine Medical Equipment Ventilators for Hospital ICU use

Packaging
Size	1. 560560605mm 2. 6707001160mm
Weight	1. 35KG 2. 79KG
Packaging Details	the normal package is wooden box(Size: LWH). If export to european countries,the wooden box will be fumigated.

FAQ
1. Who are we?
We are based in Jiangsu, China, start from 2008,sell to South America(21.00%),Africa(18.00%),Eastern Europe(14.00%),Southeast Asia(12.00%),Domestic Market(10.00%),Oceania(7.00%),MID East(5.00%),Western Europe(5.00%),South Asia(3.00%),North America(00.00%),Eastern Asia(00.00%),Central America(00.00%),Northern Europe(00.00%),Southern Europe(00.00%). There are total about 301-500 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.What can you buy from us?
Anesthesia Machine,ICU Ventilator,CPAP System,Nitrous Oxide Sedation System,Sleep Therapy System

4. Why should you buy from us not from other suppliers?
10 years experiences for ICU products 5 new products are launched very year CE approvded products have been installed in over 150 countries Good markets are Europe,Asia,America market 196 people working here to make sure high quality Won UN tenders

5. What services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,FCA,CPT,DDP,DDU,Express Delivery,DAF,DES;
Accepted Payment Currency:USD,EUR,CAD,AUD,HKD,GBP,CNY;
Accepted Payment Type: T/T,L/C,D/P D/A,Credit Card,Western Union,Cash;
Language Spoken:English,Chinese,Spanish,Korean
