Harbin Core Tomorrow Science & Technology Co., Ltd.
China Manufacturer with main products: Piezo Actuator, Piezo Stage, Piezo Nanopositioning Scanner, Piezo Objective Scanner, Piezo Tip Tilt Platform, Piezo Steering Mirror, Piezo... |
Home
>Products Catalog > Piezo Controller > Piezo Controller & Piezo Amplifier for Driving Piezo Actuator
Piezo Controller & Piezo Amplifier for Driving Piezo Actuator
| FOB Price: | 350.00 - 9999.00 USD/Piece |
|---|---|
| Supply Ability: | 500,000 Piece(s) per Year |
| Shipping: | DHL express |
| Payment Terms: | T/T |
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Heilongjiang in China |
| Packaging Details: | 30cm by 30cm by 40cm |
Quick Details
- Brand Name: CoreMorrow
- Accuracy: nanometer
- Magnification: no
- Measuring Time: no
- Single Prism: no
- Model Number: P76
- Output voltage: between -1000V to +1000V
- Bandwidth: up to 20MHZ
Specifications
P76 series piezoelectric objective scanner features a large load capacity up to 500g, Z-axis linear motion range up to 200μm, adopting flexible hinge mechanism, no friction, good linearity, high closed-loop positioning accuracy.
Technical Data
Channels |
Type |
Analog input |
Output voltage |
Frequency |
Ave. Current |
Peak current |
Ripple |
1~3 |
E03.00.9 |
-2~+10V |
-20~+100V |
10kHz |
70mA |
1000mA |
5mV |
E03.00.10 |
-1.67~+10V |
-20~+120V |
58mA |
1000mA | |||
E03.00.11 |
-1.33~+10V |
-20~+150V |
46mA |
1000mA | |||
E03.00.12 |
-2~+10V |
-20~+100V |
30kHz |
70mA |
210mA | ||
E03.00.13 |
-1.67~+10V |
-20~+120V |
58mA |
174mA | |||
E03.00.14 |
-1.33~+10V |
-20~+150V |
46mA |
138mA | |||
E03.00.15 |
-1~+10V |
-20~+200V |
35mA |
105mA | |||
E03.00.16 |
-0.67~+10V |
-20~+300V |
23mA |
69mA | |||
E03.00.17 |
-10~+10V |
-100~+100V |
35mA |
105mA | |||
E03.00.18 |
-10~+10V |
-150~+150V |
23mA |
69mA | |||
E03.05.1 |
0~+10V |
0~+100V |
50kHz |
70mA |
210mA | ||
E03.05.2 |
0~+10V |
0~+120V |
58mA |
174mA |
Channels |
Type |
Analog input |
Output voltage |
Frequency |
Ave. Current |
Peak current |
Ripple |
1 |
E05.00.1 |
-2~10V |
-20~+100V |
1kHz |
350mA |
1050mA |
5mV |
E05.00.2 |
-1.67~10V |
-20~+120V |
291mA |
873mA | |||
E05.00.3 |
-1.33~10V |
-20~+150V |
233mA |
700mA | |||
E05.00.4 |
-2~10V |
-20~+200V |
175mA |
525mA | |||
E05.00.5 |
-0.67~10V |
-20~+300V |
116mA |
348mA | |||
E05.00.6 |
-0.5~10V |
-20~+400V |
87mA |
260mA |
10mV | ||
E05.00.7 |
-1~+10V |
-20~+200V |
5kHz |
175mA |
525mA | ||
E05.00.8 |
-1~+10V |
-0.67~+10V |
-20~+300V |
348mA | |||
E05.00.9 |
-1~+10V |
-200~+200V |
87mA |
260mA | |||
E05.00.10* |
-1~+10V |
-300~+300V |
116mA |
348mA | |||
E05.00.11 |
-1~+10V |
-20~+200V |
175mA |
525mA | |||
E05.00.12 |
-0.67~+10V |
-20~+300V |
116mA |
348mA | |||
E05.00.13 |
-2~+10V |
-20~+100V |
10kHz |
350mA |
1000mA |
5mV | |
E05.00.14 |
-1.67~+10V |
-20~+120V |
291mA |
1000mA | |||
E05.00.15 |
-1.33~+10V |
-20~+150V |
233mA |
1000mA | |||
E05.00.16 |
-1~+10V |
-20~+200V |
175mA |
1000mA | |||
E05.00.17* |
0~+10V |
0~+600V |
5kHz |
120mA |
350mA |
10mV | |
E05.03.1 |
-2~+10V |
-20~+100V |
30kHz |
250mA |
750mA |
5mV | |
E05.03.2 |
-1.67~+10V |
-20~+120V |
205mA |
615mA | |||
E05.03.3 |
-1.33~+10V |
-20~+150V |
170mA |
510mA | |||
E05.03.4 |
-1~+10V |
-20~+200V |
125mA |
375mA |
10mV | ||
E05.03.5 |
-0.67~+10V |
-20~+300V |
85mA |
255mA | |||
E05.03.6 |
-10~+10V |
-100~+100V |
125mA |
375mA | |||
E05.03.7 |
-10~+10V |
-150~+150V |
85mA |
255mA | |||
E05.05.1 |
0~+10V |
0~+100V |
50kHz |
250mA |
750mA | ||
E05.05.2 |
0~+10V |
0~+120V |
50kHz |
205mA |
615mA | ||
E05.05.3 |
0~+10V |
0~+40V |
100kHz |
625mA |
1875mA |
20mV | |
E05.05.4 |
0~+10V |
0~+40V |
150kHz |
Channels |
Type |
Analog input |
Output voltage |
Frequency |
Ave. Current |
Peak current |
Ripple |
2 |
E06.00.A2 |
-10~+10V |
-300~+300V |
1kHz |
5mA |
15mA |
20mV |
4 |
E06.00.A4 |
Channels |
Type |
Analog input |
Output voltage |
Frequency |
Ave. Current |
Peak current |
Ripple |
1 |
E07.00.1 |
-10~+10V |
±300V |
3kHz |
35mA |
438mA |
10mV |
E07.00.2 |
0~+10V |
0~1000V |
30mA | ||||
E07.00.3* |
-10~+10V |
0~2000V |
30mA |
above is only part of specs. More specs please contact with us.
