Grewin Industrial Group Co., Ltd.
China Manufacturer with main products: Coil Winding Machine, Digital Motor Winding Machine, Toroidal Taping Machine |
GWL-6200 Toroidal Transformer Winding Machine Wire Winding Machine
| Payment Terms: | L/C, D/A, D/P, T/T |
|---|
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Tianjin in China |
Quick Details
- After-sales Service Provided: Engineers available to service machinery overseas
- Certification: ISO9001:2015
- Brand Name: GREWIN
- Type: coil winding machine
- Condition: New
- Warranty: long-term
- Weight: 90kg
- Dimension(L*W*H): 500x600x700
- Model Number: GWL-6200
- Computerized: Yes
- Equipment model: GWL-6200
Specifications
SPECIFICATION:
Equipment model |
GWL-6200 |
Winding mode |
Gear type |
Finally complete the outside diameter |
60-120 |
Minimum finished inside diameter |
35 |
Maximum completion height |
80 |
Suitable winding diameter range |
0.2-0.7 |
Diameter of wire storage ring |
195 |
Width of storage ring |
9-12 |
Maximum speed |
800 RPM |
Operating voltage |
220V/50HZ |
Overall dimension |
500x600x700 |
Weight |
90KG |
FEATURES:
1.Toroid Transformer Winding Machine are advanced,strongly built workhorses capable of winding light as well as heavy wire without insulation damage.
2.the open gap gear rack and hinged gap magazine of Toroid Transformer Winding Machine facilitate core change ,maximzing output.
3.Easily exchangeable magazines secure maximum flexbility.
4.Extremely powerful,maintenance free AC motors for main drive and core rotation.
5.High technical winding shuttle for winding by highest efficiency.
6.Toroid Transformer Winding Machine can accurately count length of loading by limited-switch.
7.Toroid Transformer Winding Machine can accurately count turns of winding and taping by photo-electricity sensor.
ADVANTAGES:
1.Stable machine performance
2.Communicate parameters in a timely and thoughtful manner
3.Wide range of application, Large range of Speed adjustment, wide range of the wire diameter, Multi-style of core, Brake tension adjustable, Good settlement for large outer diameter, small inner diameter, heavy wire coils.
4.High production efficiency, increase winding efficiency by adjustment of suitable brake tension,
5.Each wiring part guarantee no wire damage.
6.Parts highly optimized and universal for general use, Easy maintenance
7.Complete specifications and data
PACKAGING:
Packaging Material: Carton/Wooden case with foam inside.
1.General package(Paper carton or plastic bag): for small euipped parts for Toroidal Transformer Winding Machine, Package it with form and pack paper to guarantee unbroken during the transport.
2.Wooden case package: for larger scale Toroidal Winding mAchine,we have special skilleD carpenter, who would make the proper wooden case with exact thickness,density,length. the up arrow ↑marked on the outer wooden case. Buffer material would be put in the wooden case to prevent crack and shock.
