| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Hunan in China |
| Packaging Details: | inner plastic film and wooden case |
Quick Details
- Coil Number: Autotransformer
- Coil Structure: Toroidal
- Phase: Three
- Usage: Power
- Brand Name: Varelen
- Model Number: SCB10
- Dry type Transformer: Distribution Transformer
- Cast Resin: Power Transformer
Specifications
Winding Coil
HV/ LV winding
Foil winding
the winding coil is made of oxygen-free copper, class H for main insulation materials and coil is insulated by NOMEX paper of DUPONT brand, LV winding is isolated by copper foils. All these make the heat-resistant is up to 220℃, with excellent overload capacity and low loss, but high efficiency.
Magnetic core
the three-limb iron core is made of oblique cut Grain-oriented, seven-step silicon steel laminations insulated on both sides, guaranteeing low losses and low noise. these values are even improved by laser treatment. It is protected on the surface with a flash-proof varnish in order to prevent the sheet from corrosion and to reduce the noise.
Clamping frame
It is processed by CNC cutting, bending and then one-time punch forming, the hole's size is accurate and the appearance looks delicate.
Customer Photos
Customer Photos
Exhibition
Packaging&Shipment
