Shenzhen Zhihua Chemical Co., Ltd.

China Manufacturer with main products: Mold Making Silicone Rubber, Life Casting Silicone Rubber, Insole Making Silicone Rubber, Electronic Potting Silicone Rubber, Pad Printing...

Home >Products Catalog > Molding Silicone Rubber for Making Resin Products Mold

Molding Silicone Rubber for Making Resin Products Mold

FOB Price:	6.00 - 8.00 USD/Kilogram
Supply Ability:	8 Ton(s) per Day
Shipping:	by sea
Payment Terms:	T/T, Western Union

In Stock

Inquiry Now

Related products from verified members

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Guangdong in China
Packaging Details:	1:1 mix ratio: 20KG;25KG and 200KG Per drum

Quick Details

Brand Name: DC silicone
Color: translucent
Sample: 1kg sample is available
appearance: liquid
MOQ: 100kgs
Model Number: DC-A25
Hardness: 25 shore A
Cure Time: 3-5hours
Shrinkage rate (%): <0.1%
Elongation (%): >500%
Tensile- strength (MPa): >4.8
Shelf life: 12 Months
Mixed Viscosity: Brushable

Specifications

Application

DC-A25 silicone Rubber is Mainly used for Making molds of concrete stone, GRC, polyurethane products; wax, candle decoration; rapid prototyping and tire molds; chocolate, candy and similar products' Molding.

Description

DC-A25 is a kind of two part silicone rubber in addition cure or platinum cure type with mixing ratio of 1:1.It can cure at room temperature as well as under heat. It's a kind of skin safe and food grade.and mainly used for mold making.

Model

Color

Mixing ratio (%)

Pot life (mins,

under 25℃)

Curing time

Hardness ( Shore A )

Tensile-

Strength (MPa)

Tear-

Strength (kN/m)

Viscosity

(after A/B mixed,mPa.S)

Shrinkage

Rate (%)

Elongation

(%)

DC-A25

Translucent and aDjustable

1:1

30-40

(3-5hrs under 25℃);

(20-30 mins under 60℃)

25±2

>12

>28

5500±1500

<0.1%

> 600%

Characteristics

An exceptional fluidity and good operability, easy toDemold

AGing resistance, high temperature resistance (220℃-300℃)

ENvironmentally, food-grade

Good tensile and tear strength

Outstanding bubble releasing

Very Low shrinkage

Non-deformation

Operation Instructions

Step 1: prepare the original molds

Prepare an perfect original mold and clean it totally before operation.

Notes:MAke sure your original molds and operation tool were cleaned up totally to avoid uncured problem.

Step 2: Take 100 G part A and100 GPart B and mix them evenly.

Notes: Addition cure mOld MakingSilicon rubber isTwo parts flowing liquid, Pls follow the step strictly:

1.Weigh the two part exactly by electronic weight. If any part not in exactly weight, it may cause changing of hardness, or even cause uncured problem.

2.MIx part A and part B evenly. OTherwise the silicon rubber will be partly solidified and this will give birth to difficulties in your final operation. What's more, the finished molds will meet a short life. All of these will cause a waste of silicone rUbber.

Step 3: PourIng casting operation

Notes:1. We suggest use pouring operation way, which will be very easy to operate and demould. Pourable silicone require low viscosity which will be easy to flow smoothly and easy to de-air.

2.We suggest to set the silicone mold for another 12 hours after demould before you put it into a large production.

Warm Tips:

as addition cure silicone is a kind of platinum cure system, which will be easy to cause uncured problem,so pls kindly follow the tips as below:

Do notMix withLiquidCondensation silicone rubber or even the tool which used for condensation silicone rubber.

Do not mix withOrganic matter which Contains N, S, P organics and ionic compound like Sn, as,Hg, Ph. (Do not smoke when you use thIs addition silicone rubber)

Do not add any pigment or powder into the addition cure silicone rubber without any testing toPrevent uncureD problem.

PAckage:

1.1:1 mix ratio: 20KG;25KG and 200KG Per drum

SHelf life:

Twelve(12) months when storedunder Dry and cool place by original package under25℃
