Cost of Steel Structure Building Metal Frame Truss Grid Customization

FOB Price:	18.00 - 74.00 USD/Square Meter
Supply Ability:	2,400 Ton(s) per Month
Shipping:	Sea Transportation, Qingdao Port
Payment Terms:	L/C, D/P, T/T

In Stock

Inquiry Now

Related products from verified members

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Henan in China
Packaging Details:	container

Quick Details

Material: Steel
Brand Name: Canglong
Application: workshop,warehouse,garage,hangar,shed,house
size: Customizable
Type: Light Steel Frame
Model Number: CL-22561
Column and Beam: Hot Rolled or Welded H Section, I Section
Steel Grade: Q235B, Q345b
Service Life: >50 Years

Specifications

Compared with traditional buildings, steel structure buildings are a new type of building structure - the whole building is made of steel. the structure mainly includes steel beams, columns, trusses and other components made of thin-walled steel and steel plates. It connects parts to parts by welding, bolts or rivets. Its structure is light and simple, and is widely used in large factories, stadiums, super high-rise buildings and other fields.

Items		Specification
Main Steel Frame	Column	Q235, Q345 Welded H Section Steel
Main Steel Frame	Beam	Q235, Q345 Welded H Section Steel
Secondary Frame	Purlin	Q235 C and Z purlin
	Knee brace	Q235 Angle Steel
	Tie Rod	Q235 Circular Steel Pipe
	Brace	Q235 Round Bar
	Vertical and Horizontal Support	Q235 Angle Steel, Round Bar or Steel Pipe
Maintenance system	Roof Panel	EPS Sandwich Panel / Glass Fiber Sandwich Panel / Rock Wool Sandwich Panel / PU Sandwich Panel /Steel Sheet
Maintenance system	Wall Panel	Sandwich Panel / Corrugated Steel Sheet
Accessories	Window	Aluminiumn Alloy Window / PVC Window / Sandwich Panel Window
	Door	Sliding Sandwich Panel Door / Rolling Metal Door / Personal Door
	Rainspout	PVC
Live load on Roof		in 120kg/Sqm (Color steel panel surrounded)
Wind Resistance Grade		12 Grades
Earthquake-resistance		8 Grades
Structure Usage		up to 50 years
Finishing Options		Vast array of colors and textures available
Paint Options		Alkyd paiting, two primary painting, two finish painting (gray paint, red paint, white paint, epoxy zinc etc. ) or Galvanized.

Steel construction provides affordable, durable and low maintenance solutions for workshops, warehouses, agricultural buildings, garage buildings and aircraft hangars. Compared to wooden structures, steel can resist strong winds, heavy snow and termites. the interior layout of the metal building can be completely customized to suit your needs.

Advantages
1. Free to design architectural drawings for you;
2. Features: Fast and flexible to assemble, safe, thermal and noise insulation, water proof and fire prevention;
3. Cost-effective: Fast and easy installation greatly shorten the construction time which reduce the costs;
4. Durability: the whole structure is easy in maintenance, which can be used for more than 50 years.
5. Perfect design: Perfect design completely avoids leaks and water seepage. Meanwhile, it's also in line with the national level of fire prevention.
6. Carrying capacity: Can resists the impact of strong wind and seismic performance and bears heavy snow loads
