Diesel Engine Trainers Vocational Training Equipment

P.N.: ZCAT-1002

Technical Parameter:
1. Dimension: 1500x1000x1800mm
2. Working temperature: -40C~50C
3. Suitable car or engine models listed below:

Product Description:

the Diesel engine trainers Vocational Training Equipment displays the basic principles and structures of electronically controlled diesel engine, and simulates its operation.

Product Composition:

Main Features:
1. the engine is working properly and smoothly. It can truly show the structure and the working process of the electronically controlled diesel engine.
2. the pressure gauge installed on the laboratory bench panel shows the fuel gauge
3. the digital meter shows the voltage change of each sensor.
4. the vacuum pressure gauge installed on the laboratory bench panel shows the intake vacuum pressure
5. the injector pulse and a throttle opening degree of change value are displayed clearly by the LED lamps.
6. Laboratory bench panel is inkjet complete electronic control system schematics and detection terminal. Various sensors, actuators, and other signal parameters, voltage, resistance, frequency, etc. Can be detected by instruments
7. Diagnostic block installed on the bench can be connected to a dedicated or universal auto decoder. and engine self-diagnostic functions like reading fault codes from the engine electronic control system, clearing fault code and reading data stream.
8. Fault setting function: Multifunction switch, optional intelligent integration system or intelligent fault set appraisal system.(equipped with a communication interface and network interface )
9. after setting the fault, the trainees can use the dedicated instrumentation to check out the location and content of the set point of failure through the fault troubleshooting exercises.
10. Optional functions:
this optional feature is the use of PLC or microcontroller program control to build a network system. All the student terminals has a same control circuit diagram and same detection point to the experimental station control panel. When the teacher set a fault, all the students can detect the same fault.
11. Other models can be made according to customer's requirement
