Quick Details
- Rated Power: 500
- Frequency: 50
- Speed: 1500
- Output Type: AC Single Phase
- Brand Name: Meao
Specifications
about DOOSAN Series Diesel Generator
MEAO DOOSAN Series Diesel Generators are powered by DOOSAN engines,which have the advantages of high reliability,easy maintenance and long continuous running hours. MEAO has been cooperated with DOOSAN engine several years,and praised from the customers around the world,eg.Military,traffic engineering system,industrial and mining enterprises and other industry preferences.
Advantages of DOOSAN Diesel Generator
Small size
Excellent performance
24h after-service
Environmental-friendly
International warranty service
EU emission standard
Spare parts are easy to get from worldwide market with competitive price.
Standard Configuration of DOOSAN Open Type:
Doosan engine
Stamford/Marathon alternator
DSE6020, Smartgen control system
Base fuel tank for option
ABB,Schneider, Chint breaker
Battery and battery switch
Industrial silencer and flexible exhaust hose
500KW Doosan diesel generator:
Unit model: 500GF
Common power (KW): 500
Spare power (KW): 552
Frequency: 50 hz
Output voltage: 400/230V
Speed: 1500 RPM
Power factor: COS φ =0.8 (lag)
Unit fuel consumption (LIR/HR): 123.6
Rated output current (A): 900
Number of phases/wires: three-phase and four-wire
Noise LP7m: 98dB
Dimensions (mm): 3200*1300*1700
Weight: 4200 kg
Diesel engine data:
Model: DP180LA
Cooling mode: closed water circulation cooling
Start mode: 24V DC start
Cylinder number: 10
Fuel supply: direct injection
Cylinder arrangement: V type
Medium cooling mode: medium cooling (air-to-air)
Fuel model: Domestic 0# light diesel
Speed regulation: electronic speed regulation
Compression ratio: 15:1
Oil model: WD/40
Cylinder diameter/stroke: 128/142mm
Air intake: turbocharged
Capacity: 18.273 L
Generator data:
Model:MP-D500
Material: pure copper
Insulation grade: H
Voltage control mode: AVR
Voltage: 4% or less
Rated voltage (V): 400/230
Protection level: IP23
Frequency: 50 hz
Phase number/wiring: three phase four wire /Y type winding
Frequency adjustment rate (%): ≤±0.5 (steady state) +10 ~ -7 (transient)
Voltage adjustment rate (%): ≤±0.5 (steady state) +20 ~ -15 (transient)
Frequency volatility (%): ≤±0.5
Voltage fluctuation (%): ≤±0.5
