15~19 Panel PC Supports I5-3470 I3-3240 & I7-3770 Processor
| FOB Price: | 980.00 - 1899.00 USD/Piece |
|---|
-
ECVV Safebuy Services
According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
-
Safebuy Service Guarantee
Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.
Quick Details
- Brand Name: Anxin Intelligent
- Type: Panel PC
- Products Status: Stock
- aluminuine frame: 6mm thickness
- Memory Capacity: 4G
Specifications
IPC-15 i7 is a Panel PC supports i5-3470 i3-3240 and i7-3770 Processor. industrial all in one version supports i5-3470 i3-3240 and i7-3770 Processor with touch screen, DVI, VGA, Audio, 2 LAN, 6 USB,Sata SSD/HDD and RAM size is option, Optional to equipped6 COM, 5x RS232 and 1x RS485/422, OEM is accepted for industrial automation equipments. Supports Microsoft Windows 7/8, Microsoft Windows 10, Linux. It is suitable for any harsh industrial environments.
12.1~19" size LCD screen are alternatives for your projects
. 100~240V AC Power adapter/9~36V DC optional., They are support European,Asian,US or UK power cord.
Features
- 15" TFT SXGA LED Panel (1024 x 768) industrial all in one panel PC
- Supports Intel Core i7/i5/i3 processor
- System supports 1 x DDR3 DIMM slot,up to 8G 1066/1333MHz SDRAM
- 6x COM (1x RS485), 1xDVI, 1x PS/2, 1xVGA, 6x2.0 USB, 2xLAN, 1x Audio & MIC
- Offers 1xPCI Expressx16 slot and 1 xMini PCIe slot, for expansion
- Rear panel with power LED and HDD LED Indication, Built-in 2x 3 Watts stereo speaker
- Wireless LAN with antenna (optional), GPIO (optional)
- Robust aluminum with IP65 compliant front bezel design
- Modularize design for easy installation and maintenance
- Panel ( Flush ) mount with clip or Standard VESA 75/100mm support stand, wall mount and swing arm
Specifications
Main System
- CPU Intel Core i7/i5/i3 Sandy bridge Processor with1066/1333 MHz FSB
- Chipset Intel H61 chipset
- System Memory 1x DIMM DDR3 800/1066/1333 SDRAM up to 8 GB; Preload 2GB RAM
- LAN 2x Realtek RL8111x (Gigabit ) 10/100/1000Ethernet
- HDD (hard disk ) 2.5" SATA HDD; Preload 320GB HDD
- Audio Realtek ALC662, 5.1 channel surround Audio
- I/O Connector 5 x RS-232
1 x RS422/485
1x DVI-D port
1x PS/2 (Keboard/mouse)
1x DB-15 Connector
1x Audio (Mic-in / Line-out)
2x 10/100/1000MLAN port ( RJ-45 )
6x USB2.0
1x 3Pin DC power input terminal block - Expansion 1xPCI Express x16 Slot, 1 x Mini PCIe slot
General
- Construction Aluminum front bezel and Aluminum chassis
- Color Black or OEM(>=100 units)
- OS Support Windows 10/8/7, Windows XP, Linux
- Mounting Panel mount or Standard VESA 75/100mm
- Power supply Input Voltage: 8~30v, with External AC adapter; Output Rating 92W
LCD display
- Display type 15" XGA TFT LCD LED Backlight
- Resolution 1024 x 768 pixels
- Luminance 450 CD/m2
- Viewing angle 160°(H), 160°(V)
Touchscreen
- Type Analog Resistive 5-wire
- Controller Interface Internal USB interface controller
- Resolution Continuous
- Light Transmission 81% or more
- Operating Force ≤100g
- Life Expectancy 35 Million
Environmental
- Operate temperature -10°C~ 60°C (-14~140°F)
- Storage temperature -20°C ~ 70°C (-4 ~ 158°F)
- Storage humidity 5% to 95% @40°C non-condensing
- Vibration 17 to 500HZ 1G PTP
- Operating Shock 1G /peak ( 11m sec)
- Ingress Protection Front panel: IP65
Packing info
- Dimensions(WxHxD) 406 x 312 x 90mm
- NET weight 8.5 KG
