Toyota Automatic Transmission Training Bench

Specifications

[Product Introduction]
the training bench uses Toyota A340E original electric automatic transmission as the basis, speed control three-phase motor as the power source, the automatic transmission can be gear display, gear shift and other test conditions of actual operation. Real display of electric automatic transmission composition structure and principle and working process. Suitable for all types of colleges and training institutions on the theory of electronically controlled automatic transmission and maintenance training needs of practical training. The training bench training function is complete, easy to operate, safe and reliable, beautiful and generous.


[Structure composition]
Toyota A340E automatic transmission assembly, automatic transmission control unit, gear lever assembly, transmission oil heat sink, instrumentation, three-phase speed control motor, throttle body assembly, engine crankshaft sensor and signal panel, diagnostic seat, pressure gauge, fault setting system, the original car circuit schematic board and detection terminals, mobile stand, etc. Equipped with practical training guide and operating instructions for the stand. the sensors and actuators are installed with digital display table, main oil pressure gauge, casters with locking universal, stainless steel hand guard, high temperature and rotating parts of the table are equipped with protection devices.


[Functional features]
1. Automatic transmission normal operation, diode display solenoid valve working condition.
2. Fault simulation system can simulate the actual operating conditions, set a variety of real car automatic transmission common faults.
3. Pointer type pressure gauge indicates the main oil pressure value.
4. the training bench panel is painted with colorful spray-painted circuit diagrams, spray-painted with Plexiglas protection, students can intuitively control the circuit diagrams and engine objects, recognize and analyze the working principle of the control system.
5. the training bench panel is installed with detection terminals, the panel can directly detect the sensors, actuators, such as resistance, voltage, current, frequency, waveform signal, etc.
6. Equipped with the original car diagnosis socket, you can use the computer diagnostic instrument to read the fault code and data flow of the automatic transmission electronic control system.
7. the training bench is equipped with a power switch, and other rotating parts of the protective cover and other safety protection devices.
8. the transmission can be used for various practical training projects. the transmission can be shifted/automatic gear lift and other practical tests.
9. the base part of the training table adopts steel structure welding, panel cabinet stamping and forming, panel cabinet and base can be separated, the surface of the table frame adopts baking paint technology, with universal self-locking casters device.
10. Appearance size: 1500mm X 1000mm X 1700mm (length X width X height), weight: 200KG
