Jinan Ruby Laser Technology Co., Ltd.
China Manufacturer with main products: Co2 Laser Power Supply, CO2 Laser Engraving Machine, CO2 Laser Cutting Machine, Fiber Laser Cutting Machine, Fiber Laser Marking Machine, CO2... |
One Exnon Lamp 150W/200W YAG Jewelry Laser Welding Machine
| FOB Price: | 2.00 - 4.00 USD/Set |
|---|---|
| Supply Ability: | 20 Set(s) per Month |
| Payment Terms: | T/T |
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Shanghai in China |
| Packaging Details: | wooden box |
Quick Details
- After-sales Service Provided: No overseas service provided
- Certification: CE
- Usage: Jewelry ,mould repair,battery, golden,silver welding
- Brand Name: Rubylasertech
- Voltage: 220VAC
- Warranty: ONE YEAR
- Power(W): 6.5KW
- Dimensions: 850mmx500mmx600mm
- Max. Output Power: 200/150W
- Focal Spot Diameter: 0.1MM
- Wavelength: 1064NM
- Pulse Width: 20MS
- Single Pulse Energy: 80J
- Model Number: RW-150/RW-200Y
- Condition: New
- PACKAGE: WOODEN BOX
- delivery time: 6 days after payment received
- laser mode: nd YAG
Specifications
One exnon lamp 150W/200WYAG Jewelry Laser Welding Machine
Advantage
1.the YAG jewelry laser machiner is high precision (0.1-2mm spot size)welding method and laser beam is very thin.
2. the 150W laser welding machine'sfrequency can reach 20HZ.
3. Jewelry,glasses frame,mould,dental teeth needs laser welding way which have beautiful welding joints by this spot welding laser welding machine..
4.Jewelry laser welding machine is widely used in all kinds of metal like gold,sillver,bronze,aluminum.Steel and titanium.
5. 150watt YAG laser welding machine is new product, this product can help you win client trust on high level jewelry welding industry
6.Our company manufactureand develope YAG pulsed power supply which have big advantage in prices and after sale service.
7.24 hours and 7 days technical support can be offered.
8. Two lase welding head and 2 pcs fiber cable are optional
Specification
Product Name: Mini Spot Gold Silver Jewelry Laser Welding Machine Factory Price
Model No. RW-150Y/RW-200Y
Laser Source: Nd YAG pulsed
Laser Wavelength: 1064nm
Rated Power: 150W/200W
Laser Energy:80J /100J
Pulse Width: 0.1-20ms
Pulse Frequency: less than 35Hz
Beam Diameter:0.1-3.0mm
Power Supply: 220V±10% /50Hz and 60Hz compatible
Observing System:microscope or CCD camera
Chamber Illumination: LED circle lamps
Parameters Memorization: 10 groups
Protection Alert: flow alert
Language Display: Chinese/English
Shield Gas Supply: One line(Argon)
Cooling System: External water chiller or built-in water chiller
Power Consumption: 6.5KW/ 7.5KW
Welding Chamber Dimension: 340mmx540mmx180mm(LxWxH)
Machine Dimensions:Welder:850mmx500mmx600mm (L*W*H)
Chiller:430x370x585mm(LxWxH)
Running Environment: 5℃-30℃, 5%-75% humidity
Net Weight:150kg(welder)+65kg(chiller)
