Ningbo Hotion Cable Co., Ltd.
China Manufacturer with main products: Fire Resistant Fire Alarm Cable, Security Alarm Cable, Solar Cables, Telephone Cable, Speaker Cable, RVV Cable, BV Power Cables, Blasting... |
Fire Alarm Cable Belden Alarm Cable E90 Fire 2 Core
| FOB Price: | 0.30 - 0.50 USD/Meter |
|---|---|
| Supply Ability: | 10,000 Meter(s) per Week |
| Shipping: | Ningbo |
| Payment Terms: | L/C, T/T, Western Union |
-
ECVV Safebuy Services
According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
-
Safebuy Service Guarantee
Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Zhejiang in China |
| Packaging Details: | pallet/box |
Quick Details
- Brand Name: Hotioncable
- COLOR: red/white
- Material: Solid Bare Copper
- Size: 0.8/1.0/1.5/2.5
- Sample time: 14
- Model Number: PH30/60/120
- 2core: red
Specifications
FIRE ALARM CABLE
Fire Resistant Type
Stranded Conductor BS6387 EN50200 PH30
KEY APPLICATIONS
Fire detection and fire alarm systems for buildings.
Voice alarm systems and emergency voice communication.
Emergency and escape lighting.
Control circuits for fire safety and fire fighting systems.
TECHNICAL DESCRIPTION
Operating Voltage 300/500V
Test Voltage(50Hz) 2.0kV
Conductor Stranded Bare Copper
Insulation Material Silicone Rubber
Jacket Material LSZH
STANDARDS
BS EN 50200 - PH30 Fire Resistant Test - Flame & Shock - 30 Minutes
BS EN 50200 - PH60 Fire Resistant Test - Flame & Shock - 60 Minutes
BS EN 50200 - PH120 Fire Resistant Test - Flame & Shock - 120 Minutes
BS 6387 Category CWZ Fire Resistant Test
TECHNICAL DATA
Number of cores |
Nominal cross Section Conductor [mm2 |
Nominal jacket outer diameter [mm] |
Cable weight [kg/km] |
Conductor Resistance at 20° C [Ohm/km] |
2 |
0.8 |
5.7 |
47.5 |
23.8 |
2 |
1.0 |
6.1 |
52 |
19.5 |
2 |
1.5 |
7.1 |
70 |
13.3 |
2 |
2.5 |
8.3 |
98.5 |
7.98 |
4 |
0.8 |
6.7 |
76.5 |
23.8 |
4 |
1.0 |
7.2 |
85.6 |
19.5 |
4 |
1.5 |
8.1 |
116 |
13.3 |
4 |
2.5 |
10.4 |
185 |
7.89 |
