Automotive Basic Electrical System Training Table

Specifications

I. Product introduction.
the practical training system is based on the real car lighting system, integrating all relevant control switches and actuators into a demonstration board, which systematically shows the working principle of the car lighting system. It can be used for demonstration experiments, fault diagnosis, data measurement and other practical training operations of automotive headlights, taillights, hazard warning lights and other systems.

II. Functional features.
1. Real runnable automotive lighting system, fully demonstrate the composition of the automotive lighting system structure and work process.
2. Training table integrated placement of the left headlight assembly, right headlight assembly, front fog light assembly, left rear tail light assembly, right rear tail light assembly, combined instrumentation, body control unit, gateway control unit, combined light switch, etc.
3. the training bench measurement panel is painted with colorful spray-painted circuit diagrams, installed with detection terminals, which can directly detect the electrical signals of each headlight, rear taillight and body control unit pin on the panel, such as resistance, voltage, current, frequency signals, etc.
5. the training bench is equipped with fault setting system, which can set one and more common faults to simulate the circuit faults of automobile lighting system to achieve the purpose of examination and assessment.
6. the training table is installed with diagnostic socket, which can be connected to special or general-purpose cars to read fault codes, clear fault codes, read data streams and other self-diagnostic functions of the automotive lighting system.

III. the material and process.
1. Training table measurement panel using 8mm thickness of high-strength acrylic sheet spray-painted, with a large temperature difference, wear-resistant, moisture-proof, anti-corrosion, not easy to deformation, long service life, bright colors, not easy to fade and other characteristics.
2. Training table made of high-grade steel, with high strength, corrosion resistance, long life, etc., without the need to go through the spraying process, more environmentally friendly, more beautiful and high-grade appearance, the table with self-locking casters device, mobile and flexible, safe, reliable, durable.
3. Training table with two practical and beautiful drawers for placing daily teaching supplies.

IV. Teaching content:
1. Knowledge of the configuration of automotive lighting system
2. Understand the control principle of automotive lighting system
3. Master the basics of automotive lighting system
4. Master the working principle of the lighting system
5. Be able to independently enumerate and explain the components of the lighting system
6. Master the operating conditions of the actuators of the lighting system
7. Independently troubleshoot, maintain and repair the automotive lighting system

V. Technical parameters.
1. External dimensions: 1600 700 1800mm (L W H)
2. Input power supply: AC 220V ± 10% 50Hz
3. Working power supply: DC12V
