Product Details

Place of Origin:	Fujian Fuzhou in China

Specifications

GCM Series is a multi-purpose washing & drying machine, developed by Fortune scientific research group independently and mainly used in flat glass. This machine is not only suitable for common glass, but also widely used for coated glass, doubling glass, tempered glass, vacuum craft glass and low-e glass, which have high wash requirements.Features:1) Adopt PLC by Mitsubishi and Industry Control products by Schneider and apply automatic LPC program control system in the whole operation2) Adopt unique four pairs of brush roller (intensive curve brushed), three pairs of air-knife 3) Washing section and drying section can be lifted up or down automatically, and there are numbers displaying the thickness adjustment 4) Whole rubber roller transmitting structure, and the mandrel of the robber roller is thick-walled seamless steel pipe 5) Water channel, water skip, washing section and the spindle nose of the rubber roller of the washing section are all made of stainless steel 6) Indefinitely variable transmission system (oblique tooth gear structure)Performance parameter:1) Washing width: 300mm - 2500mm2) Washing thickness: 3mm - 30mm3) Washing spend : 0.6 - 6m/min4) Speed adjustment: speed can be steplessly adjusted5) Water supply: supply water circularly6) Input voltage: 380VAC 50Hz7) Number of brush roller: 4 pairs8) Number of air-knife: 3 pairsMajor fittings:1) Programmable controller host computer: Mitsubishi brand2) Frequency-changer: Mitsubishi brand3) Human Machine interface: Hitech brand4) Contactor: Schneider brand5) Switching element: Schneider brand
