SHANGHAI JIXIN AUTOMOBILE SALE CO.,LTD
China Manufacturer with main products: CNHTC Heavy Truck Series:HOWO Truck, STEYR Truck, STEYR-KING Truck, HUANGHE PRINCE Truck, HOJUN Truck, STEYR-GOLD PRINCE Truck. |
Related products from verified members
| Place of Origin: | Shanghai China |
|---|
Specifications
The Technical Datas ENGINE Make- STEYR Diesel 4 stroke direct injection diesel engine. Engine model- WD615.69, Euro II emission standard. 6-cylinder in-line with water cooling, turbo-charging and intercooling. Maximum output-336hp(247kw) at 2200 rpm according to DIN. Maximum torque-1300Nm at 1300-1600 rpm. Displacement-9.7261 CLUTCH Single-plate dry coil-spring clutch, diameter 420 mm, hydraulically operating with air assistance. TRANSMISSION ZF transmission, model 5S-150GP,synchromesh, 9 forward&1 reverse. PROPELLER SHAFT Double universal joint propeller shaft with gear-shaped coupling flange. FRONT AXLE Rigid stubaxle with double T-cross section. REAR AXLE Pressed axle housing, central single reduction with hub reduction and differential lock between wheels and axles. Ratio-5.73 CHASSIS Frame - U-profile parallel ladder frame with section of 300x80x8 mm, all cold riveted cross members. Front suspension- 9 semi-elloptic leaf springs with width of 90 mm, hydraulic telescopic double-action shock absorbers and stabilizer. Rear suspension- 15 leaf semi-elloptic springs with width of 90mm and bogie spring. Aluminium fuel tank- 200 L capacticity with locking fuel cap, fitted to the side of the chassis. STEERING ZF power steering, model ZF8098, hydraulic steering with power assistance. Ratio-26.2 BRAKES Service brake- dual circuit compressed air brake Parking brake(emergency brake): spring energy, compressed air operating on rear wheels. Auxiliary brake- engine exhaust valve brake. Option-ABS WHEELS&TYRES Rims-8.5-20,10 hole-steel. Tyres-12.00-20 tube Option- 12R20 tube.12R24 tube and 12R22.5 tubeless. DRIVES CAB Standard cab, all-steel forward control,70?hydraulically tiltable to the front,2-arm windscreen wiper system with three speeds, laminated windscreen with casted-in radio aerial, adjustable air suspension driver'S seat and rigid adjustable co-driver'S seat,with heating and ventilating system, exterior sun visor, adjustable roof flap, stereo radio/cassette recorder, safe belts, adjustable steering wheel, air horn, air conditioner. ELECTRICS Operating voltage: 24V, negative grounded Star
