Shanghai Fukang Machinery Manufacture Co., Ltd.
China Manufacturer with main products: gokart, go kart, gokarts, go karts, buggy, buggies |
Related products from verified members
| Place of Origin: | Shanghai Shanghai in China |
|---|
Specifications
Technical Specifications 1)Dimension: 2240X1300X1450mm(88X51X57 in. ) 2)Seat Height: 550mm(22 in. ) 3)Wheelbase: 1515mm(60 in. ) 4)Front Track: 1300mm(51 in. ) 5)Rear Track: 1240mm(49 in. ) 6)Ground Clearance: 160mm(6 in. ) 7)Type: 172MM, Single, 4-stroke, water-cool 8)BoreXStroke: 72X60mm 9)Displacement: 244ml 10)Compressive Ratio: 10: 1 11)Max. Power & RPM: 10.6/ 6500 kw (r/min) 12)Max. Torque & RPM: 18.4/ 5000 Nm(r/min) 13)Min. Unloading RPM: 1500 r/min 14)Engine Rotate Direction: Counterclockwise (Output Power Plug) 15)Ignition: C. D. I 16)Lubrication: Force & Splash 17)Starting: Electric 18)Unloading Weight: 270 kg(595lbs) 19)Clutch: Automatic of-axis 20)Transmission: CVT 21)Reducer Ratio: 2. 64X2. 5=6. 6 22)Front Wheel Size: 19X7-8 23)Rear Wheel Size: 22X10-10 24)Front Wheel Pressure: 120 k Pa 25)Rear Wheel Pressure: 120 k Pa 26)Carburetor: Constant vacuum diaphragm 27)Spark Plug: DPRTEA-9(NGK) 28)Air Box: Paper Element 29)Battery: 12V 9Ah 30)Gas Tank Capacity: 10L(2. 27gal) 31)Gas Brand: Above 90# No Lead 32)Lubricate Brand: SAE 15W-40/SF 33)Top Speed: 70km/h 34)Starting Performance: 15s 35)Brake distance@30 km/h: 7m 36)Climbing: 20% 37)Acceleration: 11s (100m) 38)Limits and measurement of noise: 80dB(A) 39)Emission of pollutantsIdle SpeedCO: 4.0CO.% (HC): 1000HC(PPm) Key Features: 1)EEC road legal. 2)250cc Liquid Cooled 4 Stroke Engine 3)Automatic Transmission w/ Reverse 4)Fuel meter 5)Digital Speedo 6)Emergency Brake 7)Chain drive system 8)595 lbs net weight 9)Keyed Electric Start 10)Wrapped Steering Wheel 11)Top speed is 75km/h(50mph) 12)3 wheel Hydraulic Disc Brakes 13)Front Headlights and Rear Taillights 14)Open & close look appearance is optional 15)Adjustable Front / Rear Hydraulic Suspension 16)Adjustable Racing Seats with 4 Point Harness 17)Front (Left and Right) Fully Independent Dual A-Arm Suspension 18)Color available in: Red, Blue and Black, other customized color is negotiable. 19)Accessory: Top canvas and buggy cover.
Service Guarantee
-
Free Service Charge
ECVV doesn't charge any service fee to Buyers for buying this product.
-
ECVV Supply
ECVV is responsible for supply, and provides product quality inspection, fund supervision and supply chain services.
-
Product Quality Commitment
ECVV China Sourcing Agent will assess the reputation and supply ability of the factory and conduct field trips to select the high-quality Chinese factories for buyers.
-
Deposit Service Commitments
In order to improve the quality of service, ECVV will charge for a 100CNY deposit for the agent purchasing order, and the deposit will be part of subsequent purchasing costs.
After paying a deposit, if the purchasing order is not completed because of unsatisfied ECVV services, ECVV will refund your deposit.
250cc Go Kart from this supplier
FOB Price: 100.00-500.00 USD/Piece
Min Order: 3 Pieces
Min Order: 20FT CONTAINER
