Home >Products Catalog > Unlimited Length Tile Machine

Unlimited Length Tile Machine

FOB Price:	10000.00 - 100000.00 USD/Set
Supply Ability:	20 Set/Sets per Month
Payment Terms:	L/C, T/T(Bank Transfer)

In Stock

Inquiry Now

Related products from verified members

Rolling Shutter Roll Forming Machine / Rolling ...

Price:19,800.00-21,500.00 USD/Set

Min. Order:1 Set
Tile-Roof Panel Roll Forming Machine

Price:

Min. Order:
Round Mosaic Tile

Price:

Min. Order:
FD27-192-960 Step Tile Forming Machine

Price:14,999.00-39,999.00 USD/Set

Min. Order:1 Set
Artificial Stone Production Line / Stone Crushe...

Price:10,000.00-1,000,000.00 USD/Set

Min. Order:1 Set
Hydraulic Pressure Roof Tile Making Machine

Price:30,000.00-80,000.00 USD/Piece

Min. Order:1 Piece
EPS/ROCKWOOL sandwich panel line

Price:100,000.00-150,000.00 USD/Set

Min. Order:1 Set
ZCW120 Roof Tile and Artificial Stone Making Ma...

Price:30,160.00-32,540.00 USD/Set

Min. Order:1 Set

Product Details

Place of Origin:	Liaoning in China

Specifications

Unlimited length ridge tile machine

FEATURES AND USAGE The machine is suitable for the large and small roof projects as well as the rain proofing and waterproofing project and beautiful appearance of the roof of the complex sheet and flat sheet. The machine can press the ridge tile with the unlimited length, which can avoid the phenomena of leakage of rain and breakage at the places of seams and joints.

MAIN TECHNICAL SPECIFICATION 1. Size: 3500mm × 800mm × 1100mm 2. Total weight: about 1200KG 3. Power: 1.5KW 4. Working speed: 20000mm/min

ridge capping forming machine

Description:	This machine is designed for manufacturing high quality steel ridge capping for steel stepped tile. This machine contains our experiences in 35 years and many times improvements by our engineers. In our service, we support the equipment and profile that customers really need and including our most sincere recommends.
Specifictions:	Thickness of Forming Sheet: 0.4 ~ 0.6 mm (Pre-painted steel). Forming Speed: 4 ~ 6 M/min. Roll Shaft Diameter: 60 mm. Number of Station: 8 ~ 10 sets. Main Motor: 7.5 HP. Complete with mandrel type uncoiler and hydraulic cutting device. Complete with one set of crimping mold. This machine is controlled by computer system with touch screen.

Features:

1. Professional designing for manufactures steel ridge capping.

2. Programmable Logic Controller (PLC) - Automatically continually manufactures high quality products.

3. Man Machine Interface (MMI) - Directly input the data by the touch screen.

4. Hydraulic drive, shear and crimping device.

5. According to Customers' requirements to design the products.

6. High speed running with hydraulic system save time and cost.

7. One year warranty.

Composition of the equipment:

1. Cold Roll Forming Machine (1 set)

2. Reel Type Uncoiler (1 set)

3. Rear-Cutter (1 set)

4. Crimping device (1 set)

5. Pre-Cutter (Option)

6. Safety Guide (Option) emergency stop wire, PVC coveretc
