LY-15-50 Preparation booth

Supply Ability:	30 Set/Sets per Week
Shipping:	10 days in deposit
Payment Terms:	L/C, T/T

Inquiry Now

Related products from verified members

Silicon Rubber Heater with CE

Price:

Min. Order:5,000 Pieces
transparent sight glass

Price:1.00-60.00 USD/Piece

Min. Order:5 Pieces
Double tube infrared heat lamp for Vamp Heating...

Price:10.00-30.00 USD/Piece

Min. Order:5 Pieces
1kg-2kg-5kg-10kg gold/copper melting induction ...

Price:500.00-3,000.00 USD/Set

Min. Order:1 Set
Pool Heater

Price:

Min. Order:
Electric cone baker with 2 head

Price:

Min. Order:5 Units

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Shandong in China
Packaging Details:	Seaworthy paking in 1*20GP

Specifications

Inside dimension: 15000*5000*5000mm(L*W*H)
Outside dimension: 15144*6896*5600mm(L*W*H)
Pit: 2 rows of pits in the ground for exhaust air, dimension of each pit is 13000*750mm(L*W*H)
Main door: 4-folds, 4000*4500mm(L*W*H), colour: White
Personal door: 2 units, 700*2000mm(W*H), insulation is polystyrene, colour: White
Room body: 3 uints supporting steel in the wall and 3 unitd profiled bar beams in the roof to strengthen the room body; Wall panel thickness: 70mm, width: 550mm, tongue and groove structure, 0.476mm colour steel with polystyrene insulation inside, colour: White
Lighting: Ceiling lights: 18units*4PCS=72PCS*36W Side lights: 14units*4PCS=56PCS*36W, vertical( left side 6 units, right side 6 units, rear side 2 units)
Generaor setting: Intake air from side upper direction, exhaust air from back upper direction, quadrate steel frame, outside is white coated steel, inside is galvanized steel
Intake and exhaust air system (2 units): In total 4*7.5KW double-intake centrifugal fans for intake air, model YDW5.6m, air capacity is 20000m^3/h for each fan; 2*11KW double-intake centrifugal fans for exhaust air, model TAE-710H, belt-drive, air capacitity is 36000m^3/h for each fan
Heating system (2 units): 2PCS RIELLO RG5S oil burner, heating productivity: 520000Kcal/h, 2PCS stainless steel heat exchangers, 2 electric dampers from spraying to baking cycle
Filtering system: Pre-filter, high efficiency filter (ceiling filter), floor filter (fibreglass), M-shape activited carbon filter, extract fibreglass filter repaced by level side
Roof panel: 50mm thick EPS heat preservation panels
Higheast working temperature: 80 centigrade
Control panel: Spraying, heat spraying, baking, time setting, lighting switch, failure indicator, temperature controller, power supply switch, emergency stop, hour meter, temperature limit controller
Power supply: As request
Free air speed: Is more than or equal to 0.25m/s
Lllumianance: Is more than or equal to 450LUX
Total power: 57.5KW
