5R 200W Beam Moving Head

Specifications

200w 5R sharpy beam moving head light

1. We have Black case and white case. Please tell me what color you need when you make order. If have not told, we ship Black one .

2. There are two Plug Type, EU and US plug, we send priority EU plugs. If you need to specify the US plugs, please leave us a message, otherwise, we will send Eu plug, thank you.

Professional manufacturer of beam 200w sharpy 5r moving head light 16/8 prism

Description:

Voltage: AC100-240V 50/60Hz

Power Consumption: 230W

Lamp: Philip lamp 200W

Effect: Perfect parallel, laser-like beam, sharply defined and free of any halo

Channel mode: 16/20 channels can be selected when using

Language: English and Chinese can be selected when using

Motor: 13 Motors

Beam angle: 0-3.8 degree

Colors: Interchangeable color wheel with 14 fixed colors

Gobos: Interchangeable gobo wheel with 17 fixed gobos

Lens: glass lens

Frost Effect: Frost Filter

Pan/Tilt scan: 540/270 degree (16bit) Electric correction

Color temperature: 8500K

Dimmer: 0-100% mechanical dimming

Strobe: Mechanical shutter and adjustable speed strobe effect

Heat protection: Automatic break in power supply in case of overheating or failed operation of cooling system

Product Size: 523x337x411mm

Packing Size: 48x44x57cm

Net Weight: 19.5kg

Gross Weight: 23.5kg

Advantages:

Body

Aluminium structure with die-cast plastic cover

Two side handles for transportation

Device locking PAN and TILT mechanisms for transportation and maintenance

Electrinicos:

Long life self-charging buffer battery

Pre-set macros

Function reset from the lighting desk

ON/OFF lamp control from the lighting desk

"AUTOTEST" function from menu

ETHERNET ready

Electronic monitoring with status error

Cooling system monitoring

DMX level monitoring on all channels

Internal data transmission diagnostics

Firmware upgrade with no power

Firmware upload from another fixture

SAFETY DEVICES

Bipolar circuit breaker with thermal protection

Automatic break in power supply in case of overheating or failed operation of cooling system

Forced ventilation with axial fans

WORKING POSITION

Any Working Position

Hanging system: with fast-lock omega clamps (1/4 turn) on the base

OTHERS

Eco-friendly: replaces far larger and more expensive spotlights

Electronic ballast fitted as standard

Available in mirror-finish chrome version

Magnetic ballast and AC/Dc power supply

Packing:

1. Each light will have one Power Plug(Europe countries---Europe Standard Plug, USA, Canada, Mexico---USA Standard Plug. If ship to other countries, please tell me which plug you need before our shipping).

2. Each light will have TWO Clamps/Hooks and the pair screws.

3. Each light will have one safety lock.

4. Each light will have one DMX Cables.
