Home  >Products Catalog > Notepad making machine series > Laebl punching machine LPM series

Laebl punching machine LPM series SafeBuy Supplier Member

Shipping: 30% advance payment be paid by TT, balance paymen shall be paid before shipment
Payment Terms: L/C, T/T
Export Markets: North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin: Zhejiang in China
Packaging Details: Standard export package

Quick Details

  • Type: Labeling Machine
  • Certification: CE
  • Weight: depends on machine size
  • Dimension(L*W*H): depends on machine size
  • Power: depends on machine size
  • Voltage: 380v/50hz/3PHASE (the voltage can change with surcharge)
  • Driven Type: Hydraulic
  • Condition: New

Specifications

Feature:
Label cutter LPM with raw waste mouth is is suitable for the production of not only all kinds of material labels including paper labels, leather labels, textile labels, and also plastic cards, playing cards, aluminum foil, aluminum plastic, New year card, note book, name card, envelopes of any design of size with an average speed about 900000 pcs per hour. This machine adopts hydraulic pressure system.

With a push-cube self-adjusting to every position of the " V" hold where the pack is positioned in order to obtain a homogeneous pression and distribution of the paper, the working table has a photoelectric cell which gives maximum safety to the operator and allows a quick change of the hollow punch and is adaptable both for low and medium production. The working process is completely stability. The die cutting products surface is smooth, and the size is unified and regular with high precision.


Technical parameter:

Model

LMP-150

LPM-220

LPM-280

LPM-400

LPM-500

Max cutting size/

Max diameter

100*100mm

141mm

150*150mm

212mm

190*190mm

269mm

270*270mm

382mm

340*340mm

481mm

Min cutting size

55*40mm

55*40mm

90*70mm

120*120mm

150*150mm

Cutting distance

200mm

200mm

200mm

200mm

200mm

Cutting pressure

16KN

30KN

40KN

50KN

50KN

Working speed

12000sheets

/min

12000sheets

/min

12000sheets

/min

12000sheets

/min

12000sheets

/min

Power

1.5kw

2.2kw

3kw

4kw

4kw

Weight

300kg

560kg

900kg

1140kg

Packing size(mm)

1200*850*1400

1450*850*1500

2300*850*1600

2500*1040*1660

2700*1140*1860


LaeblpunchingmachineLPMseries
