Hebei Weijia FRP Co., Ltd.| Manufacturer
Hebei Weijia FRP Co., Ltd.

China Manufacturer with main products: FRP Pipe, FRP Tank, FRP Vessel, FRP Grating, Cable Tray, Molding Grids, Pull Extrusion Profile, Packed Tower

4th
Home  >Products Catalog > cable tray > FRP Fire proof Cable Tray supply china factory/Green color frp cable tray for power cables

FRP Fire proof Cable Tray supply china factory/Green color frp cable tray for power cables SafeBuy Supplier Member

FOB Price: 0.29 - 1.98 USD/Meter
Supply Ability: 3,000 Meter per Day
Shipping: by sea, by air
Payment Terms: L/C, T/T
In Stock
Export Markets: North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin: Hebei in China
Packaging Details: carton inner, then plastic film and wooden pallets packing for container loading

Quick Details

  • Dimensions: 130mmx120mm 4m x 3.1mm thickness
  • Technique: extrusion pulling
  • Surface Treatment: extrusion
  • Application: for cable holding
  • Model Number: C-03003
  • Brand Name: WJ
  • Mechanical strength high: epoxy resin
  • rigidity of the metal bridge and toughness of the glass steel bridge: use in highly corrosive environment
  • corrosion resistance: large span
  • anti aging performance is strong: heavy load conditions
  • handsome in appearance: red
  • installation is convenient: green
  • service life is long: yellow

Specifications

FRP Fire proof Cable Tray

Specifications


all kinds of material:Q195,Q235,SS304,SS316,steel,FRP.you can choose any color

product description

1 all kinds of material
 2 Top Cable Tray suppliers 3 High quality Cable Tray 4 Low Cost Cable Tray 5 UL,CE,ISO9001

Cable tray material

1. Carbon Steel

2. Pre Galvanized Steel Plate (GI, G.l.)

3. Stainless Steel SS304 and SS316L

4. Aluminum

5. FRP (GRP, Fiberglass)

Cable tray finish

1.Pre Galvanized (GI, G.I.)

2. Hot Dip Galvanized (HDG)

3. Electrostaticspraycoating

PACKING;

1. Bulk
2. Wooden box
3. Stretch film packaging
4. According to customer's requirement

PAYMENT TERM:

30% T/T in advance, 70% upon receiving the shipping advice by the seller



General Introduction

In the electrical wiring of buildings, a cable tray system is used to support insulated electric

cables used for power distribution and communication. Cable trays are used as an alternative to open wiring or electrical conduit systems, and are commonly used for cable management in commercial and industrial construction.


 Feature:

 * Light weight

* Low cost

* Unique shape

* Easy installation

* Good heat dissipation and ventilation



 Application range:

It generally applies to large power cables laid, especially suitable for high and low voltage power cables.



Material

* Common cable trays are made of galvanized steel,  aluminum, or glass-fiber reinforced plastic.

* The material for a given application is chosen based on where it will be used.



Main Parts & Accessories

Various clamping, supporting and splicing accessories are used with the cable tray to provide a

complete functional tray system.



Main Parts:

1.Straight segments

2.Horizontal elbows(Various shapes including tees and crosses.)

3.Supporting arm

4.Hanger bracket

5.Connection accessories





 Specification:





Size

Weight( kg)

Width(A)mm

Height(B)mm

50

25

7.95

100

50

14.70

150

75

20.30

200

100

36.41

250

125

40.81

300

150

47.47

400

200

79.20

500

200

90.01

600

200

101.68

800

200

125.13
