Large Size GRP Water Tanks

Specifications

SMC combined water tank is made of SMC molded veneer, sealing material, metal structure and piping system assembled. Its unique performance to solve the large concrete water tank weight, easy leakage, easy long moss and steel water tank of the easy corrosion coating shedding of water pollution problem, and has the advantages of good water quality, no leakage, light weight, beautiful appearance, long service life, convenient installation, etc.

The SMC water tank is applicable to industrial and mining enterprises and institutions, residential, hotels, restaurants and other public buildings. As living water and the water quality requirements of the higher food, medicine, health essential water storage device.

H=2m FRP water tank is assembled by moulding single panels, sealing aterial, metallic parts and pipeline.
Tank of different height uses different thickness of bottom panels, side panels and top panels strictly according to the assemble principle.

Manufacturing Process :
SMC hot pressed compression moulding

Tank Structural Support :
External : Standard Type : Hot Dipped Galvanised Steel
Optional Type : External Braced type (Metal-Free tank internal for non-
partitioned tank only).

Internal : Standard Type : SS 304 Tie-Rod or Cleat / Angle Stay
Optional Type : SS 316 Tie-Rod or Cleat / Angle Stay

Roof Support : PVC Vertical Poles and GRP roof panel stiffener

Sealant :
Non toxic PVC foam

Bolt, Nuts, Washers :
External : Standard : Hot Dipped Galvanised Steel
Optional : SS 304/A2 or SS 316/A4

Internal : Standard : SS 304/A2 (In-contact with water)
Optional : SS 316/A4 (In-contact with water)
Roof : Hot Dipped Galvanised Steel or unless otherwise specified

Ladder :
External - Standard : Hot Dipped Galvanised Steel
Internal - Standard : PVC
- Optional : GRP or 316
