Home  >Products Catalog > roller bearing > FAG SKF FBF Axial Thrust Bearing 29340EM Thrust Roller Bearing 29340EM for Machinery

FAG SKF FBF Axial Thrust Bearing 29340EM Thrust Roller Bearing 29340EM for Machinery SafeBuy Supplier Member

Supply Ability: 5,000 Piece(s) per Month
Shipping: delivery within 3days
Payment Terms: T/T, Western Union, MoneyGram, Safebuy, Paypal
Export Markets: North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin: Shanghai in China
Packaging Details: 1. generally packed in poly tube or poly bag and into paper box and then into carton box. If the goods are too heavy, we suggest to use wood case or wood pallet. 2. according to customers requirement.

Quick Details

  • Type: Roller
  • Structure: Thrust
  • Seals Type: Seal or Open
  • Precision Rating: P0 P6 P5 P4
  • Outside Diameter: 0-400 mm
  • Bore Size: 0-200 mm
  • Brand Name: FBF SKF
  • Number of Row: Single Row
  • Model Number: 29340EM
  • Type:: Roller
  • Size:: 140*200*46 mm
  • Weight:: 29.5 KG
  • Clearance:: C2 C0 C3 C4 C5
  • Application:: Papermaking machinery, railway, gear box bearing, vibrating screen
  • Material:: chrome steel-stainless steel-carbon steel-plastic-ceramic
  • Certification:: ISO9001:2008

Specifications

FBF SKF Axial thrust bearing 29340EM Thrust roller bearing 29340EM for machinery

Product Name
Thrust roller bearing 29340EM
Model Number
29340EM
Brand Name
FBF
Structure
Thrust roller bearing
Type
Roller
Material
Chrome Steel, Carbon Steel
Cage material
Steel , brass
Vibration
Z1V1 Z2V2 Z3V3
Precision Rating
P0 P2 P4 P5 P6
Number of Row
Single Row
Guarantee
One year
Dimension
200*340*85 mm
Application
Motor, Machinery, Electric Tools,Sports Apparatus, office equipment.
Certifications
ISO 9001:2008, SASO,CE,PVOC

Axial thrust bearing 29340EM Thrust roller bearing 29340EM for machinery


the roller of this type of bearing is
 Spherical shape, and the spherical raceway of the housing washer has self-aligned function. this type of bearing can support very big axial loads, meanwhile it can support certain radial loads. Oil lubrication is commonly used during work.
Furthermore, this bearing has the self-aligning capability which is as good as spherical roller bearings.

this type of bearing is mainly used in hydroelectric generators, vertical motors, propeller axle of vessels, tower cranes, squeezing presses, etc.

Designation Dimensions Mass
  D (mm) D (mm) H (mm) kg
29422 110 230 73 33.4
29424 120 250 78 18.5
29326 130 225 58 9.8
29426 130 270 85 23.9
29330 150 250 60 12.5
29430 150 300 90 29.3
29334 170 280 67 16.5
29434 170 340 103 42.4
29338EJ 190 320 78 25.6
29438EJ 190 380 115 60.3
29340 200 340 85 29
29440 200 400 122 69.8
29344 220 360 85 33.9
29444 220 420 122 73.9
29348 240 380 85 41.9
29448EM 240 440 122 78
29352 260 420 95 51.2
29452 260 480 132 103
29360 300 480 109 76.6
29460 300 540 145 136
29364 320 500 109 79.8
29468 340 620 170 220
29372 360 560 122 113
29476 380 670 175 261
29576 380 820 265 824
29380 400 620 132 165
29284EM 420 580 95 70
29388 440 680 145 180
29488 440 780 206 411
29392 460 710 150 220
29496EM 480 850 224 550
294/500 500 870 224 560
293/530 530 800 160 288
293/600 600 900 180 635
294/630 630 1090 280 1170

Axial thrust bearing 29340EM Thrust roller bearing 29340EM for machinery
Axial thrust bearing 29340EM Thrust roller bearing 29340EM for machinery
Axial thrust bearing 29340EM Thrust roller bearing 29340EM for machinery
