Jinhong Plastic Hardware Mould Fittings Co., Ltd.
China Manufacturer with main products: Mold Components, Hardware Mould Fittings, Guide Strip |
Jinhong Plastic Mold Components Slider Series DTK
| FOB Price: | 1.00 - 999.00 USD/Set |
|---|---|
| Shipping: | shenzhen |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram, Safebuy |
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Guangdong in China |
Quick Details
- Brand Name: Jinhong
- Grinding precision: 1
- Gemeral precision: 1
- EDM precision: 1
- material origin: Jinhong
- Model Number: DTK
Specifications
this product is installed on the ejector pin knockout plate of the mould and is required to be equipped with a formed inclined ejector pin. after molding, the product automatically lubricates through the internal mechanism during the ejection process of knockout plate, and the concave and convex mould core is ejected on the inner side of the molded plastic part within the specified stroke, so that the plastic part can be demoulded smoothly.
| Code | d | h | Q | d1 | b1 | b2 | e | F | Stroke | MT | MH |
| DTK-08 | 8 | 8 | 7 | 4.5 | 24 | 20 | 7 | 10 | 10 | M4 | M3 |
| DTK-10 | 10 | 10 | 5.5 | 32 | 30 | 9 | 12.5 | 18 | M5 | M4 | |
| DTK-12 | 12 | 12 | 10 | 7 | 39 | 35 | 11 | 15 | 20 | M6 | M6 |
| DTK-16 | 16 | 16 | 12 | 9 | 46 | 40 | 14.5 | 25 | M8 | ||
| DTK-20 | 20 | 20 | 14 | 11 | 56 | 55 | 18 | 16 | 30 | M10 | M8 |
| DTK-25 | 25 | 25 | 16 | 14 | 66 | 65 | 22.5 | 17 | 35 | M12 | M10 |
| DTK-30 | 30 | 30 | 18 | 74 | 70 | 27 | 40 | ||||
| DTK-35 | 35 | 35 | 20 | 85 | 80 | 32 | 18 | 45 | M12 | ||
| DTK-40 | 40 | 40 | 25 | 18 | 95 | 90 | 36 | 19 | 50 | M16 | |
| DTK-45 | 45 | 45 | 30 | 105 | 110 | 40 | 24 | 55 |
