Woodworking Machine (QL-M-25)

FOB Price:	7,800.00 - 8,500.00 USD/Set
Supply Ability:	200 Set/Sets per Month
Shipping:	By sea
Payment Terms:	L/C, T/T, Western Union

In Stock

Inquiry Now

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Shandong in China
Packaging Details:	fumigating wood case

Specifications

QL-M25B Wood CNC Router

Product Features:

Highest speed at more than 32m/min and highest efficiency.

Durable and high accuracy.

High power spindle made of best steel.

Wood CNC Router is with two motors and unique two rack driving.Stable movement and no deformation or vibration after a long-time work at a high speed.

Special Axle X dust-proof system protects Axle X and ensures its high accuracy.

DSP system, no need of computer.

Standard Configurations	Options
Square Tube Lathe Bed, absorption table-board	2.2kw Dust Collector
X Y with racks, all with square guides
Axis Y with two motors
DSP System
4.5 KW Spindle and Transducer
Large Leadshine driver
5.5 KW High-power Vacuum Pump
Auto Lubrication System
Max. speed 30-40m/min

Technical Data
Working Area	1300mm2500mm200mm
Table Size	1480mm*3000mm
Max. Speed	>20m/min
Clamping	By Suction
Processor	DSP/ Speed 100MHZ
Interface	USB
Command Code	G Code.u00.mmg*.plt
Working Software	DSP
Power (not including spindle)	1840w
Working Voltage	AC380V/50HZ
Spindle Power	4.5kw
Spindle Running Speed	0-24000rpm
Motor	Stepper
