BOPP thermal laminating film SafeBuy Supplier Member

Shipping: 30% advance payment be paid by TT, balance paymen shall be paid before shipment
Payment Terms: L/C, T/T
Update Time: 2019/7/19
Export Markets: North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin: Zhejiang in China
Packaging Details: Standard export package

Quick Details

  • Usage: Packaging Film

Specifications

Advantage:

.Green and safty:

The film with no toxic , no smell , no benzene.

It will not occur any pollution gas and material during the laminating process , anti-fire which caused by the use and storage of flammable solvent .

.Function:

The film is with brilliantbondingand strong ability of absorbing powder. It improves printings color saturation and brightness, prevent the printings from blistering after die cutting &bumping. Matt thermal lamination film is applied for part UV coating , hot stamping, etc.

.Easy operation:

it is easy to operate once the required temperature is met and no special technique is required
. Efficient and energy-saving:

Production is reduced substantially as there is no film wastage, mixture of adhesive solvent, and no UV heating lamp is required.

. Adaptable to different kinds of machines:

This is widely used in dry laminator and wet laminator. Small adjustments need to be made to the machine if the film is used in wet laminator

Process parameter:

Equipment for laminating film: dry and wet laminating film machine
Temperature: normal: 85-100°C; special: 100-110°C
Roller pressure: 8-15MPa
Speed: 8-50m/min
Remarks: special laminations are those with thicker ink, solid color, high moisture content and bigger size paper



SPECIFICATION PARAMETER

SPECIFICATION

GLOSS

GLOSS

GLOSS

GLOSS

GLOSS

GLOSS

GLOSS

THICKNESS

(UM)

BASE

EVA

TOTAL

10

5

15

12

5

17

12

8

20

15

8

23

15

10

25

15

12

27

18

12

30

WIDTH (mm)

360 390 440 540 590 780 880 1080 1320 1400 1600 1880

(or customer's request)

LENGTH(m)

200-3000

CORE(inter Diameter)

25.4mm (1 inch) ; 50.8mm(2 inches) ; 76mm (3inches)

CONNECTOR

LESS THAN 2

TENSILE STRENGTH

MD:2.4*10 6 dyne/cm  CD:5.3*10 6 dyne/cm

SPECIFICATION

MATT

MATT

MATT

MATT

MATT

MATT

THICKNESS

(UM)

BASE

EVA

TOTAL

12

5

17

12

8

20

15

8

23

15

10

25

15

12

27

18

12

30

WIDTH (mm)

360 390 440 540 590 780 880 1080 1320 1400 1600 1880

(or customer's request)

LENGTH(m)

200-3000

CORE(inter Diameter)

25.4mm (1 inch) ; 50.8mm(2 inches) ; 76mm (3inches)

CONNECTOR

LESS THAN 2

TENSILE STRENGTH

MD:2.4*10 6 dyne/cm  CD:5.3*10 6 dyne/cm
