good performance FRP cable tray factory direct sell 2016

FOB Price:	0.29 - 1.98 USD/Meter
Supply Ability:	3,000 Meter per Day
Shipping:	by sea, by air
Payment Terms:	L/C, T/T

In Stock

Inquiry Now

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Hebei in China
Packaging Details:	by pallets packing for container loading

Quick Details

Dimensions: 110mmx100mm 4m x 3mm thickness
Technique: extrusion pulling
Surface Treatment: extrusion
Application: for cable holding
Model Number: C-065
Brand Name: WJ
Mechanical strength high: epoxy resin
rigidity of the metal bridge and toughness of the glass steel bridge: use in highly corrosive environment
corrosion resistance: large span
anti aging performance is strong: heavy load conditions
handsome in appearance: red
installation is convenient: green
service life is long: yellow

Specifications

FRP cable tray:
new style product on the basis of manufacturing steel cable tray.It's high mechanical strength,good insulation property, hemical corrosion resistance, fire retardant. So it's widely used for laying cables in petrol, chemical, textile, light industry, metallurgy, machine, electric power, telecommunication, underground garage and national defence project. cable tray is adequate for laying electric cable, controlling cable, lightening wires, air-powered, solvent-powered cable, which are below 10kv.

FRP cable ladder Specification:

Material	Fiber reinforced plastic(FRP or GRP)
Heigh	75mm, 100mm, 150mm, 200mm, 250mm
Width	150mm to 900mm
Thickness	4.8mm to 9.5mm
Length	3m, 6m or can be produced according to customised length)

Surface Finish:

FRP cable ladder or GRP cable ladder

Installation Notice:

Bends, Risers, T Junctions, Crosses & Reducers can be made from ladder cable tray straight sections flexibly in projects.

Trays shall be supported at a maximum span of 2m by trapeze, wall, floor or channel mounting methods and will not exceed maximum loads as specified by the manufacturer.

Cable Tray systems can be safely employed in places where the temperature ranges between -40°C and +150°C without any change to their characteristics.

The advantage of HDmann FRP cable tray

FRP perforated cable ladder mainly used in chemical industry ,it has some features like :

1.Easy to install, save space

2.Good heat dissipation and ventilation

3.High corrosion resistance

4.anti-fire,insulation

5.it's light weight ,but high intensity

6.More cheaper than other materials

Packaging & Shipping

FRP Fire proof Cable Tray

provide:

1.standard package:Plastic Film inside and Steel frame outside

2.as request

Our Services

The core value of our company is customer-orientation. All the staffs in our company has keep the corporate value in mind deeply.

Therefore, we promise:

1, the price we offered is the competitive

2, the quality of our products is excellent

3, the intention of what we are doing is to service our customers sincerely

what we can do:

1,free samples offered

2, all off-shelf products can be customized

3, 24 hours online-consultation

andeja de cable es una especie de bandeja portacables completamente cerrado de acero inoxidable, acero al carbono, FRP, aleación de aluminio. Bandejas de cables de canal han recubierto de polvo, galvanizado en caliente y electro superficie galvanizada principalmente utilizado para apoyar cables de computadora, cables de comunicación, cables de termopar y otros cables de control. Canal bandeja de cable tipo ha cerrado la cubierta para proteger los cables de la luz solar, la caída de objetos, el polvo y el agua u otro líquido.

Articulo	Modelo	Anchura(mm)	Altura	Longitud (mm)
		milimetro	milimetro	milimetro
Bandeja De Cable	WJ-01	100	50	350
			100	500
		150	100	550
			150
		200	100	600
			150
			200
		300	100	700
			150
			200
		400	100	800
			150
			200
		500	100	900
			150
			200
		600	100	1000
			150
			200
		800	100	1200
			150
			200

Características:
Bandeja de cable están completamente cerrados y pueden proteger los cables de calor, el polvo y el agua.
Electro galvanizado, superficie galvanizada por inmersión en caliente hace que las bandejas de cable canal resisten la corrosión, óxido y productos químicos.
Bandejas de cables de canal tienen la propiedad de resistencia al fuego bien.
Alta capacidad de carga para apoyar cables.
Estructura simple y bella apariencia.
Fácil de instalar con los accesorios correspondientes.
Larga vida útil.

Pliego de condiciones:
Material: acero inoxidable 304/316/316, acero al carbono, aleación de aluminio, FRP.
Acabado: recubrimiento de polvo, por inmersión en caliente galvanizado, electro galvanizado.
Longitud: 1000mm - 3000mm.
Ancho: 100 mm - 800 mm.
Altura: 50mm, 75mm, 150mm.
